• Model NO.：BZD
• Type：Cantilever
• Slewing Arm：3m
• Capacity：0.25-10t
• Power Supply：380V,400,415,440V 50,60Hz 3pH
• Electrical System Brand：Siemens,Schneider,Chint
• Lifting Equipment：Manual, Electrical Hoist
• Affiliate Documents：English Operation Manual, Wiring Diagram
• Tower Crane Type：Under Slewing Cranes
• Operation Method：Pendant, Remote Controller
• Applicable Work Duty：A3~A5
• Stepless Speed Control：Available (Variable Frequency Control)
• Transport Package：Wooden Box
• Specification：BZD
• Trademark：LYFOOCRANE
• Origin：China
• HS Code：84253190
• Production Capacity：5000

Basic Info.

Model NO. BZD Type Cantilever Slewing Arm 3m Capacity 0.25-10t Power Supply 380V/400/415/440V 50/60Hz 3pH Electrical System Brand Siemens/Schneider/Chint Lifting Equipment Manual/ Electrical Hoist Affiliate Documents English Operation Manual, Wiring Diagram Tower Crane Type Under Slewing Cranes Operation Method Pendant, Remote Controller Applicable Work Duty A3~A5 Stepless Speed Control Available (Variable Frequency Control) Transport Package Wooden Box Specification BZD Trademark LYFOOCRANE Origin China HS Code 84253190 Production Capacity 5000

Product Description

Slewing Jib Crane with 0.5t capacity
Designing Concept

Our jib crane is specially designed according to different working site, so that to give a best solution.  The working situation, such as the wind, weather, temperature, location, work duty, work type, power system etc., will all be taken into consideration.  For internatonal market, we pay much more attention to the shipping measurements, installation convininece and quality issues.
Brief Introduction

The BZD type pillar jib crane is a set of middle or small type equipment for lifting, which forms a complete set with electric hoist or manual hoist. It is usually adopted with push button or manual pulling, which is reliable and distinctive. The operated arbitrarily in three-dimensional space.  The hook approch will maximum this working area. C-track have the trolley moves smoothly.

The BZD pillar jib crane is widely used in different places of all kinds of industry. Ambient temperature should be not more than 40 oC. Controlled by push button or remote.
The pillar jib crane is forbidden to use in combustible, explosive, corrosive, electromagnetic, electric hoist, melting metal, overloading and dust works.

Product Advantage

Special designed reducer for reliable performance
Box girder (for bigger capacity) gives safety factors
Easy installation and maintenance
Limit switch for rotation, trolley and hoisting
Special painting material for outside yard
Special rotation designing for winding area (need to be clarfified)
Cost effective and fast delivering

Concrete Foundation

The jib crane must installed on a concrete foundation which starts from 1.3mx1.3m to 2mx2m. We can provide the referrence foundation drawing for client. However, client has to consider the local civil construstruction rules.


Capacity	0.5t ~ 20t
Working Radias	Up to 12m
Lift height	Upon to be requested
Lifting Speed	8m/min
Cross Travel Speed	20m/min
Rotation Speed	0.56r/min
Work Duty	A5
Controlled by	Pendant/Radio
Power Supply	380v, 3p, 50hz
