• Model NO.：QUY55
• Transport Package：Roro
• Specification：11.5× 3.47× 3.4m
• Trademark：SINOMADA
• Origin：Jiangxu, China
• Production Capacity：1000 Pieces,Per Month

ItemsUnitParameter valueMax. rated lifting load of main boom(t)55Max. rated lifting load of fixed jib(t)11.4Max. lifting load moment(t.m)203.5Max. rated lifting load of boom single pulley(t)6Main boom length(m)13~52Main boom luffing angle(°)-3~80Fixed jib length(m)7~16Max. size of single unit for transport (L×W×H)(m)12.04×3.45×3.36Installation angle of fixed jib(°)10,30Max. single line speed of hoist system(m/min)125Max. single line speed of main luffing system(m/min)87/78Max. slewing speed(r/min)2.45/2.2Max. travel speed(km/h)1.37/1.22Gradeability(%)30Average ground pressure(MPa)0.06Model-SC7H210.1G3/QSB6.7Engine power(kW)155/153Emission-National III stage/Europe IIICrane overall mass(t)46.3(Main hook,13m boom)Max. weight of single unit for transport(t)28.6
