• Model NO.：QY50K
• Shaft Number：2
• Crane Jib：Four-Arm
• Type：Straight Arm
• Transport Package：Nude
• Specification：42 Ton
• Trademark：SINOMADA
• Origin：China
• HS Code：8429521200
• Production Capacity：10,Month

Description

Unit

Parameter value

Overall length

mm

13930

Overall width

mm

2780

Overall Height

mm

3630

Axle base

1st ,2nd axle

mm

1470

2nd ,3rd axle

4300

3rd ,4th axle

1350

Wheel Base

mm

2304+2075

Front overhang/rear overhang

mm

2389/2064or 2376/2064

Front extension/rear extension

mm

2131/226 or 2144/226

Total vehicle mass in travel configuration

kg

42200

Axle load

Front axle

kg

16200

Rear axle

26000

Engine Model

WD615.338

Engine rated power

kw/(r/min)

276/2200

Engine rated torque

N.m/(r/min)

1500/1300-1600

Max. travel speed

km/h

85

Min. steady travel speed

km/h

2~3

Min. turning diameter

m

24

Min. ground clearance

mm

327

Max. grade ability

%

42

Approach angle

°

19

Departure angle

°

15

Braking distance (at 30 km/h, full load )

m

≤10

Oil consumption per 100km

L

40

Exterior noise level during acceleration traveling

dB (A)

≤88

Noise level at seated position

dB (A)

≤90
