Single Girder Gantry Crane with Good Quality Capacity 5-30t

Lyfoo Industry Co., Ltd.
  • Certification：CE, ISO9001
  • Condition：New
  • Operation Form：Air Operation+Ground Operation
  • Maximum Lifting Height：20-25m
  • Maximum Lifting Weight：20t
  • Main Girder Form：Single Girder

Base Info

  • Model NO.：MH
  • Type：Ordinary
  • Control Method：Room Control or Remote Control
  • Lifting Speed：8,0.8 7,0.7 3.5,0.35
  • Power：Customization
  • Work Duty：A3-A5
  • Cross Speed：20 M,Min
  • Long Travel Speed：20 M,Min, 5,20 M,Min
  • Stepless Speed Control：Available (Variable Frequency Control)
  • Electrical System Brand：Siemens,Schneider,Chint
  • Affiliate Documents：English Operation Manual, Wiring Diagram
  • Tower Crane Type：Under Slewing Cranes
  • Transport Package：40′ Container
  • Specification：A3-A5
  • Trademark：zhongyuanshengqi
  • Origin：Henan, China
  • HS Code：84253190
  • Production Capacity：5000 Sets,Month

Description

Basic Info.

Model NO. MH Type Ordinary Control Method Room Control or Remote Control Lifting Speed 8/0.8 7/0.7 3.5/0.35 Power Customization Work Duty A3-A5 Cross Speed 20 M/Min Long Travel Speed 20 M/Min, 5/20 M/Min Stepless Speed Control Available (Variable Frequency Control) Electrical System Brand Siemens/Schneider/Chint Affiliate Documents English Operation Manual, Wiring Diagram Tower Crane Type Under Slewing Cranes Transport Package 40′ Container Specification A3-A5 Trademark zhongyuanshengqi Origin Henan, China HS Code 84253190 Production Capacity 5000 Sets/Month

Product Description

Single Girder Gantry Crane (MH)
Full Gantry Crrane

MH single beam full gantry crane is matched with CD1/MD1 model wire rope hoist. It is a kind of track travelling midium-duty class gantry crane. The capacity from 3ton to 32ton, span from 12m to 35m or others , working temperature within-20--+40 centigrade. This gantry crane is commonly used outside yard for loading/unloading and moving materials. The control is pendant pushbutton control, cabin control or remote control. If your workshop does not have any collumn to support an overhead crane, the gantry crane can also be a solution.

Some Technical Parameter
Capacity3, 5, 10, 16, 20t
Span14-30m
Lifting Height6-15m
Power Supply380v, 3p, 50hz

Features
  - Designed for indoor & outdoor use.
  - The structure can be box type or truss type
  - Equipped by electric wire rope hoist CD/MD type or Chain hoist.
  - Power supply by cable reel system or bus bar
  - Controlled via push button pendant/Radio remote/Cabin, separately or any combination.
  - Tailored based on client's detailed requirement.

Semi-gantry crane
Inside workshop, semi-gantry is available. The top end carriage runs on runway, while bellow end carriage run on the ground. Semi-gantry crane is kind of full gantry crane, and has  the same features of full gantry crane. Semi-gantrycranes are suitable solution for the area in which overhead runways are not practical,and also impossible to build double track for crane travelling.

The leg is often designed with straight on the outside part, so that gives more hook approach.

Advantages:
1)Advanced combination of motor, reducer, brake and drum.
2) Widely used with I-beam.
3) Light duty type
4) Safe traveling
5) Fluent starting and stopping
6) Noise-less
7) Good appearance
8) Easy and convenient maintenance
9) Cost effective
10) CE certification
