• Model NO.：OKT-8T
• Type：Straight Arm
• Transport Package：Wooden Case
• Specification：8T
• Trademark：OUKE
• Origin：Shandong
• HS Code：8427900000
• Production Capacity：100

Product model

OKT-8T

Total mass kg

7900 KG

Overall dimension mm

8665mm*2095mm*2930mm

Rated elevating capacity kg

8000

Ma Lifting Moment KN.M

240

Max. Lifting Height m

25m

Main hook single load kg

8000

Main hook single elevating speed m/min

76

Auxiliary hook single load kg

600

Auxiliary hook single elevating speed m/min

53

Displacement/Power (ml/kw)

2545/70

Derailleur model

17D32F1

Wheelbase(Front/Rear)  mm

1398/1345

Wheelbase  mm

3200

Tyres

7.50-16 with spare tires  6 pieces

Max speed(km/h)

80

Axle

2

Passenger

2

Braking form

Vacuum booster

Steering form

The steering wheel circulation ball type

Crane jib structure

U shape

Main Lifting Mechanism

Category two planet wheel with a brake inside

Auxiliary Lifting Mechanism

Category one gear brake motor

Platform

Anti-skidding and big

Dynamic Motor

BMSE200

Crane Cab

Tailor-made

The central axially symmetrical

Five oil ways

Crane Start

Tailor-made

Throttle

Hydraulic

Pressure gage and switch

Shockproof component

Power Takeoff

Driving indoor operation zip type

Hydraulic Oil Tank

Turntable rear mounted, counter weight combined type, special four-layer filters

Telescopic Boom Advantages

1.Advanced development & analysis means make sure design is very reliable.

2.Using two-section telescopic cylinder design,one of the cylinders push the second large boom,another cylinder push the rest of the telescopic boom by the pulley block and wire rope.To ensure that the crane has strong lifting capacity in the middle distance and effectively protect the wire rope in the boom.

3.The more symmetrical center design of pentagon & hexagon boom made it has bigger anti-bending capacity.

4.Compact boom head and tail design,make the longest boom length,prolong the working life of the crane.

5.The integer lifting winch improved  the work efficient greatly and prolong the work life of hydraulic system.

6.Boom head adopting integral structure ,greater  intensity.Split head design reduces the boom head carrying capacity.

7.Self-design & developed slewing machine with greater drive force can meet varied requirements of working situation.

8.Lifting mechanism hydraulic winch relies on disc spring and friction brake,stable and reliable,efficient.low noise,small calorific value;Rely on hydraulic balanced valves balancing weights when falling,greatly improved product reliability.

9.Anti-slewing impulse equipment that make vehicle running safely.
