• Maximum Lifting Height：25-30m
• Maximum Lifting Weight：20-50t
• Main Girder Form：Single Girder
• Type：Ordinary
• Voltage：200-600V
• Color：as Your Requiry
• Transport Package：Plywood Cases
• Specification：CE $ ISO
• Trademark：ELK
• Origin：China
• HS Code：8425110000
• Production Capacity：2000sets,Month

Basic Info.

Maximum Lifting Height 25-30m Maximum Lifting Weight 20-50t Main Girder Form Single Girder Type Ordinary Voltage 200-600V Color as Your Requiry Transport Package Plywood Cases Specification CE $ ISO Trademark ELK Origin China HS Code 8425110000 Production Capacity 2000sets/Month

Product Description

It is typical of unique optimal structure in shortening the distance between the machine body and the beam tracks, applicable to operations inside fairly low buildings, especially suitable for use in temporarily erected plant buildings or on the sites where expansions of effective hoisting spaces inside the building is required.

1. Light aluminum alloy shell
2. Inverse phase sequence protecting device
3. Limit switch
4. 24/36V device
5. Side magnetic braking device
6. Light, handsome and durable chain bag
7. Imported FEC80 ultra heat-treatable steel alloy chain.

Type	HKDSL0301S
Capacity(ton)	1
Lifting  Height(m)	3/9
Lifting  Speed(m/min)	5.4
Power(kw)	1.5
Rotation  Speed(r/min)	1440
Phase	3
Voltage(V)	380
Frequency(hz/s)	50
