• Model NO.：ZRT600
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Folding
• Max. Load Moment of Basic Boom：2116.8kn.M
• Main Boom Length：11600 - 45000mm
• Jib Length：9500 - 16000mm
• Swing Speed：0~2.4r,Min
• Rated Working Pressure：28MPa
• Rated Working Flow：280L,Min
• Hydraulic Oil Tank Capacity：850L
• Complete Vehicle Kerb Mass：45000kg
• Front Axle Load：25000kg
• Rear Axle Load：20000kg
• Max. Travel Speed：36km,H
• Transport Package：Container,RO-RO
• Specification：14100*3300*3790mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：8426411000
• Production Capacity：100,Month

Working   performance

1

Max. rated lifting   capacity × working radius

kg.m

60000×2.5

2

Max. load moment of   main boom

kN.m

2116.8

3

Max. load moment of   main boom (fully extended)

kN.m

1197

4

Max. lifting height   of main boom (fully extended)

m

45.1

5

Max. lifting height   of jib

m

61.2

Dimensions

6

Overall dimensions   (L × W × H)

mm

14100×3300×3790

7

Outrigger spread

(Height × Width)

mm

7380×7400

8

Main boom length

mm

11600   - 45000

9

Jib length

mm

9500   - 16000

10

Boom angle

°

-2   - 80

11

Swing range

360°   unlimited swing (Full range)

Working   speeds

12

Max. hoist rope   speed (Main winch)

m/min

130

13

Min. boom   telescoping out time

s

95

14

Min. boom   telescoping in time

s

110

15

Min. boom   derricking up time

s

45

16

Min. boom   derricking down time

s

125

17

Swing speed

r/min

0~2.4

Hydraulic   system

18

Maximum working   pressure

MPa

28

19

Rate working flow

L/min

280

20

Hydraulic oil tank   capacity

L

850

Gross   vehicle mass

21

Gross weight

kg

45000

22

Front weight

kg

25000

23

Rear weight

kg

20000

Driving

24

Max. driving speed

km/h

36

25

Wheelbase

mm

3950

26

Treads

(Front / Rear)

mm

2605

27

Max. gradeability

%

75
