4ton Tower Crane 48m Boom Construction Tower Crane
SHANDONG TAVOL MACHINERY CO., LTD.- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：100-150m
- Maximum Lifting Weight：<5t
- Installation：Jack-Up
- Moving Type：Fixed
Base Info
- Model NO.：QTZ40-4808
- Type：Top-Slewing Crane
- Application：Building, Construction
- Rated Max.Load：4ton
- Rated Tip Load：0.8ton
- Free Standing Height：30m
- Max.Lifting Height：120m
- Span：48m
- Mast Section：1.5*1.5*2.2m
- Electric：Schneider
- Warranty：14 Months From The B,L Date
- Power：380V,50Hz,3p
- Transport Package：40hc Container
- Specification：SGS ISO BV
- Trademark：Tavol
- Origin：Shandong, China
- HS Code：84262000
- Production Capacity：100sets,Year
Description
Series
QTZ40
Standard Model
4808
Max. Lift Load
4t
Tip Load
0.8t
Free Standing Height
29m
Max.Anchorage Height
120m
Jib Length
48m
Mast size
1.5×1.5×2.2m
Lift Mechanism
Lifting Speed
(a=2) 70/35/9 m/min
(a=4) 35/17.5/4.5 m/min
Lift motor
15/15/4 kw
Wire rope diameter
12.5 mm
Trolley Mechanism
Trolley speed
39/26 m/min
Trolley Motor
1.5/2.2 kw
Slewing Mechanism
Slewing Speed
0.62 r/min
Slew Motor
3.7 kw
Jacking Mechanism
Jack Climbing Speed
0.4 m/min
Jack Climbing motor
4 kw
