Harbor Mobile Port Crane with Mobile Crane Price

Sinoway Industrial (Shanghai) Co., Ltd.
  • Certification:ISO9001, ISO14001
  • Condition:New
  • Application:Workshop, Warehouse, Coal Stack, Port, Wharf, Construction Site, Mine
  • Anchor:Removable
  • Structure:Lattice
  • Material:Steel

Base Info

  • Model NO.:SWMH350L
  • Type:Cantilever
  • Working Radius:10.2 M
  • Max. Lifting Height:11.3 M
  • Max. Travel Speed:15km,H
  • Max. Hoisting Moment:300kn.M
  • Warranty:One Year
  • Operating Weight:40 Ton
  • Brand:Sinoway
  • Model:Swmh350L
  • Transport Package:Nude
  • Specification:ISO
  • Trademark:Sinoway
  • Origin:China
  • HS Code:84294990
  • Production Capacity:500 PCS , Year

Description

Basic Info.

Model NO. SWMH350L Type Cantilever Working Radius 10.2 M Max. Lifting Height 11.3 M Max. Travel Speed 15km/H Max. Hoisting Moment 300kn.M Warranty One Year Operating Weight 40 Ton Brand Sinoway Model Swmh350L Transport Package Nude Specification ISO Trademark Sinoway Origin China HS Code 84294990 Production Capacity 500 PCS / Year

Product Description

Main Feature
1-Dual engine ( Electric motor + Diesel engine) more environmental protection;
2-Electric operation has over-current and heat leakage protection device;
3-Utomatic identification of phase sequence to prevent reverse rotation of oil pump;
4-Hydraulic system power-off, oil self-locking protection device;
5-Multiple compound movements during operation to improve efficiency;
6-The hydraulic system is equipped with air-cooled radiator;
7-The gripper can rotate and change direction automatically 360 degrees;
8-When electric operation is carried out in the upper control room, there is a dual-purpose air conditioner for heating and cooling;
9- Hydraulic Cabin elevatied.

Product Show
Harbor Mobile Port Crane with Mobile Crane PriceHarbor Mobile Port Crane with Mobile Crane Price

Specifications
Dimensions
Overall length15350mm
Overall height3620mm
Overall width3260mm
Wheelbase3200mm
The maximum lifting height of driving cab5320mm
Tail slewing radius4122mm
Gap between rotary table and ground1519mm
Width of platform627mm
Power
Engine132kw
Electric Motor75kw
Fuel tank295L
Walking System
Walking speed15km/h
Max.tranction force110KN
Gradeability15%
Hydraulic System
Max.flow2*160L/min
Max.working pressure28Mpa
Hydraulic oil tank420L
Pilot pressure3.6Mpa
Main Performance Parameters
Total weight35t
Max.Lifting moment100t.m
Max.swing speed3.6r/min
Max.swing torque51KN.m
