• Model NO.：qy55v
• Shaft Number：5
• Crane Jib：Three-Arm
• Type：Straight Arm
• Max. Lifting Height：58.3 M
• Boom Luffing Time：95 S
• Travel Speed：76 Km,H
• Departure Angle：13 Degree
• Total Weight in Travel：40870kg
• Fuel Consumption for 100km：37L
• Transport Package：Nude Package
• Specification：55 ton
• Trademark：zoomlion
• Origin：Changsha, Hunan
• HS Code：87051091
• Production Capacity：1000units,Month

Type

Ser. No.

Item

Unit

Value

Working performance

1

Max. rated lifting weight × working radius

kg.m

50000×3.0

2

Max. lifting torque of basic boom

kN.m

1764

3

Max. lifting torque of longest main boom

kN.m

940.8

4

Max. lifting height of longest main boom

m

42.1

5

Max. lifting height of jib

m

58.3

Dimensions

6

Outline dimensions (L×W×H)

mm

13300×2750×3650

7

Distance between outriggers (longitudinal × transversal)

mm

5920×6900

8

Main boom length (completely retracted - completely extended)

m

11.1~42

9

Jib length

m

9.5,16

10

Main boom angle of elevation

°

-2~80

11

Swing range

360°continuously

Working speed

12

Max.speed of single rope on the drum of main winch

m/min

130

13

Boom extension time

s

95

14

Boom derricking up time

s

50

15

Swing speed

r/min

0~2

Mass

16

Complete vehicle kerb mass

kg

40870

17

Front axle load

kg

15000

18

Rear axle load

kg

26000

Traveling

19

Max. traveling speed

km/h

76

20

Max. gradeability

%

40

21

Min. turn radius

m

12

22

Min. ground clearance

mm

280
