• Model NO.：LH
• Type：Double Beam Crane
• Span：5-35m
• Capacity：10+10t
• Lifting Height：6m
• Power Supply：380V,50Hz,3, Can Be Customized
• Max.Lifting Load：650t
• Sling Type：Wire Rope
• Application：Construction Usage
• Traveling Speed：20m,Min
• Affiliate Documents：English Operation Manual, Wiring Diagram
• Electrical System Brand：Siemens,Schneider,Chint
• Transport Package：Wooden Box for Electric Parts
• Specification：QD
• Trademark：LYFOO
• Origin：Place of Origin Henan, China (Mainland)
• HS Code：84261120
• Production Capacity：2000

Basic Info.

Model NO. LH Type Double Beam Crane Span 5-35m Capacity 10+10t Lifting Height 6m Power Supply 380V/50Hz/3, Can Be Customized Max.Lifting Load 650t Sling Type Wire Rope Application Construction Usage Traveling Speed 20m/Min Affiliate Documents English Operation Manual, Wiring Diagram Electrical System Brand Siemens/Schneider/Chint Transport Package Wooden Box for Electric Parts Specification QD Trademark LYFOO Origin Place of Origin Henan, China (Mainland) HS Code 84261120 Production Capacity 2000

Product Description

LH Type Double Girder Bridge Crane
1. Capacity: 5-650t
2. Span: 5-35m
3. Lifting height: 6-100m
4. Certificate: ISO 9001

LH type double girder bridge crane, its trolley is bigger and stronger than LH type, reducer and brake separately. And this is the most important factor for working 24*7 hours per day. And this kind of heavy duty crane, it is widely used in plants, warehouses, materials stocks to lift goods or materials.

LHtype crane mainly consists of two strong bridge beams, crane travelling mechanism, electric winch trolley and electric system, and could be classified into several working duties, e. G. A5, A6, A7, according to the working frequency and pure working time.

Technical featurers
1) Strong box type, welding by machine hand.
2) Wheels, wirerope drum, gears, couplings are manufactured by our CNC manchine center
3) Heavy duty slipring motor, TOP quality in China.
4) Pendent control, wireless, cabin control.

Safety features of QE crane
1)Weight overload protection device, top quality polyurethane buffer, crane travelling limit switch, low voltage protection function, emergency stop system, current overload protection function.
2)Painting: Anti-rust painting, Primer and finishing paint, yellow or red color, General thickness: About 105 microns.
3)Standard capacity: 5tons, 10tons, 16/3.2tons, 20/5tons, 32/5tons, 50/10tons, 75/20tons, 100/20tons, 100/30tons, 125/30tons, 150/30tons, 160/32tons, 200/50tons, 400/80tons, 560/250tons.

Some Technical Parameter

Capacity	5-500
span	10.5-31.5
Work duty	A3-A7
Power supp;y	Three Phrase Alternating Current
Lifting Height	12-15m

Technical Characteristics:
1) Hard-tooth surface of reducer
2) Steel winding drum
3) Imported rope
4) Converter function of adjustable speed without contact or module
5) Intelligence controlling
6) Trinity drive

Warranty
-14 months warranty when products leave the factory, or 12 months warranty after installation and commissioning in addition to the human damage factors.
-Two years spare-parts provided for better maintenances.
-Professional technical staffs provide installation, commissioning and training services.
-Delivery with English user manual, parts manual, product certification and other relevant certificates.
-Technical advisory for any time.

cause this is a kind of customized product, please kindly provide us the following information:
1. Lifting capacity.
2. Span length. (rail center to rail center)
3. Lifting height. (hook center to ground)
4. Do you need bus bar, rail from us?
5. Local power supply 380V 50Hz 3P?
6. Working condition: What goods to lift?
7. Drawings of working place would be appreciated.
