• Model NO.：STC500,STC500E5
• Shaft Number：2
• Crane Jib：Four-Arm
• Type：Folding
• Minimum Lifting Radius：3m
• Transport Package：1*40fr+6*40hq
• Specification：9300*2400*3210mm
• Trademark：SINOMADA
• Origin：China
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. STC500/STC500E5 Shaft Number 2 Crane Jib Four-Arm Type Folding Minimum Lifting Radius 3m Transport Package 1*40fr+6*40hq Specification 9300*2400*3210mm Trademark SINOMADA Origin China Production Capacity 50000PCS/Year

Product Description

China Construction Machinery 50 ton  STC500 Truck Crane  for Sale  Maximum lifting capacity: 50tOverall length: 13750mmOverall width: 2750mmOverall height: 3800mmAxle distance-1,2: 1450mmAxle distance-2.3: 4000mmAxle distance-3.4: 1350mmOverall weight: 42000kgAxle load-1,2: 16000kgAxle load-3.4: 26000kgRated power: 250kw/2100rpmRated torque: 1425N m/1200rpmMaximum travel speed: 85km/hMinimum turning radius12mMinimum turning radius of boom head14.5mDrive circuit8×4Minimum distance between the base of the car tire and the bottom of the chassis295mmApproach angle18 °Departure angle12 °Maximum incline ability40%Fuel consumption per 100 km45LTemperature range- 20 ~ + 45Minimum lifting radius3mSuperstructure tail swing radius4mBoom Cross5Boom ShapeU-shapedMaximum lifting moment - bottom of boom1774kN mMaximum lifting moment - full boom extension840.8kN·mMaximum lifting moment - full boom extension + jib318kN·mBoom base-length11.5mBoom full-length-extension43mfull-length-extension boom + jib59mOutrigger range (Longitudinal * Transverse)6×7.2mJib offset0° 15° 30°Main hoist single rope lifting speed (no load)130m/minLifting speed of single rope auxiliary hoist (no load)130m/minBoom extension/withdrawal time100/120sBoom raise/lower time80/80sSwing speed0~2 r/minHVAC in the top seatCooling/Heating
