• Main Girder Form：Double Girder
• Color：Red Per Your Request
• Lfiting Height：6m Per Your Demand
• Powe Supply：380V
• Span：22-40m
• Range：Double Girder Gantry Crane
• Application：Construction Usage
• Tower Crane Type：Slewing Tower Crane
• Sling Type：Wire Rope
• Moving Type：Wheel
• Installation：Assembled
• Transport Package：Wooden Box for Electric Parts
• Specification：CE, ISO9000
• Trademark：Shengqi
• Origin：Henan, China (Mainland)
• HS Code：84250000
• Production Capacity：30, 000

Basic Info.

Main Girder Form Double Girder Color Red Per Your Request Lfiting Height 6m Per Your Demand Powe Supply 380V Span 22-40m Range Double Girder Gantry Crane Application Construction Usage Tower Crane Type Slewing Tower Crane Sling Type Wire Rope Moving Type Wheel Installation Assembled Transport Package Wooden Box for Electric Parts Specification CE, ISO9000 Trademark Shengqi Origin Henan, China (Mainland) HS Code 84250000 Production Capacity 30, 000

Product Description

10t Mg Type Double Girder Gantry Crane
MG(A) type box girder gantry crane are usua outdoor storage, stock grounds, railway warehouses, and seaport docks. It also can be used in special operation with various hooks. It consists of four main parts, bridge structure, traveling mechanism, trolley and electric equipment. The bridge is welded structure of box-type girder. All movements of the crane are controlled from the cabin. Either rigid shapes of steel (angles or tees) or flexible insulated cable shall be selected to be utilized as runway conductors.

MG Double Beams Gantry Crane
1.Mainly made up of bridge, trolley, crane traveling mechanism and electric system.
2. Applies to the open warehouse or rail along for general handling and lifting work.
3. Also can equipped with many lifting device for special work.
4.Prohibited for lifting high temperature solution, flammable, explosive, corrosion,overloading, dust and other dangerous operations .

1.Main Girder:be welded of steel plates with honeycomb hole, connected by high-strength precision bolt. There are sliding rail for trolley to travel upper the girder which is fixed on outrigger by high-tension precision bolt.

2.Outrigger a. consist of rigid outrigger and flexible outrigger, all connection points are connected by high-tension bolt
b. the ladder is used by operator to enter into cab or arriving at winch
c. when the span>30m,there need a flexible leg aiming at reducing the lateral thrust the trolley has to the rail when the girder load objects

3.Travelling mechanism  a.the driving gear box supplys power to realize the crane's travelling.
b. what the difference between driving gear box and passive wheel box is that passive wheel box lacks transmission structure such as dynamo,
reducer and a pair of exposed gear

4. trolley with hoist  a. trolley frame welded of steel plate is the loading and travelling mechanism of trolley with hoisting
b.winch is the lifting mechanism of trolley..when it works, wire rope affects the pulley as rising and falling movement,
which makes suspended objects lifting and lowering
5. Cab  a. glass window through which one can watch overall working condition is installed in the front and two sides of the cab
b. Electric cabinet as a group of independent cabinet , fixed outside of cab is connected by control cable and linkage station which is set up in the cab

Why choose us?
        1. More than 30 years' experience and 2500 employees.
        2. More than 500 sets of manufacturing and inspection equipment.
        3. Annual production capacity: 20000 sets

     Notice: As QD is customized, please confirm following information.
        1. lifting capacity.
        2. lifting height.(hook center to ground)
        3. Power supply: Voltage.
        4. Working condition: which material to lift? temprature?
