• Model NO.：QY16V
• Type：Straight Arm
• Transport Package：Nude Package
• Trademark：zoomlion
• Origin：China
• HS Code：87051092
• Production Capacity：5000PCS,Year

ItemValueRemarksWorking performance specificationMax. rated total lifting capacity kg16000 Max. load moment of basic boom kN.m710 Max. load moment with max. main boom length kN.m408 Max. lifting height of main boom m31.08Deformation of boom is not taken into consideration.Max. lifting height of fly jib m38.8Working speedMax. speed of single rope on main winch m/min120The 4 th layer of drumMax. speed of single rope onauxiliary winch m/min108 Telescopic time of boom s55 Derricking time of boom s38 Slewing speed r/min0~3 Traveling specificationMax. traveling speed km/h75 Max. gradeability %35 Min. turning circle diameter m20 Min. ground clearance mm250 Limits for exhaust pollutants and smokeComply with related standardsGB3847-2005
GB17691-2005
(Stage III)Oil consumption per hundred kilometers L30 Mass specificationDeadweight of crane in traveling condition kg23000 Complete vehicle kerb mass kg22870 Front axle load kg6200 Rear axle load kg16800 Dimension specificationOverall dimensions(L×W×H)mm12050×2500×3400 Base on outriggers m4.95 Distance between outriggers m5.6 Main boom length m9.8~30.8 Main boom angle °-2~80 Fly jib length m7.5 Offset angle of fly jib °0, 30
