Hoisting Machinery Zoomlion Qy55D531.2r 55 Ton Right Hand Drive Truck Crane
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：-
- Maximum Lifting Weight：55t
- Shaft Number：4
- Crane Jib：Four-Arm
Base Info
- Model NO.：QY55D531.2R
- Type：Straight Arm
- Transport Package：Roro,Container
- Specification：Max Lifting Capacity: 55 t
- Trademark：Zoomlion
- Origin：China
- HS Code：87051091
- Production Capacity：500,Month
Description
ItemUnitValueRemarksWorking performanceMax. rated lifting capacitykg55000 Max. load moment of basic boomkN.m2009 Max. load moment of main boom(fully extended)kN.m1050 Max. load moment of basic boomm12.6 Max. lifting height of main boomm43.6These parameters do not include deflection of main boom and jibMax. lifting height of jibm58Working speeds Max. hoist rope speed(Main winch)m/min120 Max. hoist rope speed(Auxiliary winch)m/min120 Boom demrricking up times50 Boom demrricking up times95 Slewing speedr/min0-2 Driving parametersMax. height above sea levelm2000 Max. driving speedkm/h76 Max. gradeability%40 Min. turning diameterm≤24 Min. ground clearancemm260 Oil consumption per hundred kilometersL43 MassDeadweight in driving conditionkg42000 Complete vehicle kerb masskg41870 Front axle loadkg16000 Rear axle loadkg26000 DimensionsOverall dimensions(L×W×H)mm13700×2800×3800 Outrigger spread(L)m5.92 Outrigger spread(W)mFully extended:7.1,intermediately extended:4.8 Tail slewing radiusmm3900 Main boom lengthm11.4 - 43.0 Boom angle°-2 - 80 jib lengthm9.2,14.6Low-mounted, open-typeOffset°5,25,45
