• Model NO.：STC800
• Shaft Number：2
• Crane Jib：Four-Arm
• Type：Folding
• Overall Height：3880mm
• Transport Package：1*40fr+6*40hq
• Specification：9300*2400*3210mm
• Trademark：SINOMADA
• Origin：China
• Production Capacity：50000PCS,Year

Overall length

15290mm

Overall width

2800mm

Overall height

3880mm

Maximum engine power

276/1900Kw/rpm

Engine maximum output torque

1800/1000-1400N.m/rpm

Maximum travel speed

80Km/h

Minimum turning radius

12m

Approach angle

≥10°

Departure angle

≥14°

Maximum grade

44%

Fuel consumption per hundred kilometers

≤44L

Maximum rated total lifting capacity

80t

Turntable tail radius of gyration

4.385m

Maximum lifting moment-basic boom

3293kN.m

Maximum lifting moment-longest main boom

1803kN.m

Outrigger span (horizontal × longitudinal)

8×6.43m

Boom length-basic boom

12.96m

Boom length-longest main boom

50m

Boom length-longest main boom + auxiliary boom

67.5m

Maximum speed of single rope of main winch (no load)

130m/min

Maximum speed of auxiliary winch single rope (no load)

130m/min

Boom fully extended/retracted time

140s/160s

Full lifting/falling time of boom

65s/90s

Swing speed

 0 ~ 1.8r/min

Total mass of the whole machine

50000

Axle load-one and two axle load

24000kg

Axle load-three and four axle load

26000kg
