• Model NO.：XGC120T
• Transport Package：No
• Specification：lift capacity: 120t
• Trademark：XCMG
• Origin：China
• HS Code：87051092
• Production Capacity：500,Year

Basic Info.

Model NO. XGC120T Transport Package No Specification lift capacity: 120t Trademark XCMG Origin China HS Code 87051092 Production Capacity 500/Year

Product Description

Sammery
Model: XGC120T
Brand: Xugong Group
Place of Origin: Xuzhou, Jiangsu

details
Product Number: G5AEBDDFB2FAB0
Added time: 2018-08-23
Product gross weight: 117106.000kg
Warranty period: 12 months
After-sales service system: 7x24 hours after-sales service
Status: New
Movement mode: crawler
The whole length of the machine: 14776mm
Full width (extension/contraction) of the whole machine: 6300/3996mm
Total driving quality: 117106kg
Maximum climbing ability: 50%
Grounding specific pressure: 0.097MPa
Maximum rated total lifting capacity: 120t
Maximum lifting torque: 4165kN•m

Advantage
The max rated lifting capacity of XGC120T telescopic crawler crane is 120t, with six telescopic boom sections, two side-sited folding jib sections, 56m fully-extended boom (12.2~56m) and 10.6/18.1m jib. Its boom length can fulfill various working radius demands. Telescoping crawler track is with self-assembly and disassembly function, not only meets the high stability requirement of lifting operation, but also the outline dimension requirement for overall crane transportation.
It is mainly used for operations in special conditions with highly restricted spaces and no-pavement, such as pile in building construction site, bridge, tunnel, building interior demolition, and etc. It will show its unique advantages especially in desert, swamp and other rough working conditions.

Company Information
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2015, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.

At present, the power of my company's straight-arm crane is entirely from the hydraulic oil pressure, that is, through the high-pressure hydraulic oil to promote the cylinder piston reciprocating motion, or drive the hydraulic motor rotation makes the hydraulic winch and rotary mechanism rotation.

So, how do high-pressure hydraulic oil get? Each truck crane is equipped with a hydraulic pump when the vehicle chassis is matched, and the engine provides power for it. The chemical energy of the fuel can be converted into the crankshaft of the engine to rotate the mechanical energy, and then the gearbox gear is rotated, and then the power is transmitted to the hydraulic pump through the power transmission of the gearbox. Therefore, the hydraulic pump can continuously pressurize the hydraulic oil For the high-pressure hydraulic oil, so as to provide power for the crane to achieve the lifting of the goods.

Competitive Advantage
My company's straight arm crane crane covers 1-25 tons 14 models 65 kinds of products, to meet a variety of conditions, with the longest arm of the largest tonnage crane mature manufacturing technology, scientific research and development process, advanced Research and development technology, and constantly have new products to market, to meet customer use.
My company's boom arm section with mature pentagonal, hexagonal and octagonal, the latest generation of products with U-shaped arc arm body weight reduction, arm width of a large deflection, stability and resistance to deformation Ability to improve, significantly enhance the lifting capacity.
The application of the sub-arm, sub-winch and vice-hook provides a basis for the rapid and large-scale operation of the crane light load and the high-altitude operation. The application of automatic hook technology saves time and effort when starting and ending crane operations, making it easy to operate easily.
Our company will offer you the high quality products with a low price, quick delivery,and professional after-sale service.

FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
