• Model NO.：Stc160
• Type：Folding
• Transport Package：Nude Package
• Origin：China
• HS Code：87051091
• Production Capacity：5000pices,Year

Basic Info.

Model NO. Stc160 Type Folding Transport Package Nude Package Origin China HS Code 87051091 Production Capacity 5000pices/Year

Product Description

Brand 16 Tons Small Truck Mobile Crane Stc160
contact
Nora Li
Mobile/ :+86-17363975813

Product description

STC900T truck crane is designed with five-section boom that is made of high strength steel structure and optimized U-shaped cross section. Its maximum lifting capacity is 90 ton, full-extended boom length of 50m.

Superior lifting capacity

Five section, U Shaped main boom, the length of full extended main boom is 50 meters long, the longest in the industry. The longitudinal span is 8m with 16.1t full counterweight, the lifting capacity is leading the industry over 15%.

High bearing capacity of chassis

Brand new chassis with 2.8m width, the frame with rectangular cross section is more higher and wider, The lifting capacity of anti-torsional and anti-bending have been achieved comprehensive enhancement.

Electro-hydraulic proportional hydraulic system

Lifting energy saving capacity would be increase 15% by using electric control system than hydraulic control system, the heave load working efficiency would be increase 30%. The composite operation would be more coordinately and smoothly by using intelligent flow compensation and the utilization of flow would be increase 20%.

Humanized control system

New humanized design with handrail and ladder, the widened operation cab can move upward from 0 to 20 degree with new inner design, new air supply design of three dimensional air condition provides more comfortable and more wider working environment.

Parameter


Capacity
Max. lifting capacity	90t
Dimensions
Overall length	15290mm
Overall width	2800mm
Overall height	3880mm
Axle distance-1,2	1520mm
Axle distance-2,3	4305mm
Axle distance-3,4	1500mm
Axle distance -4, 5	2420mm
Weight
Overall weight	50000Kg
Front axle load	24000Kg
Rear axle load	26000Kg
Engine
Model	Cum mins
Rated power	275kw/2100rpm
Rated torque	1550N.m/1100-1400rpm
Emission standard	Euro 3 standards
Traveling
Max. traveling speed	85km/h
Min.turning radius	12m
Min.turning radius of boom head	15.2m
Approach angle	≥18º
Departure angle	≥14º
Max. gradeability	≥40%
Fuel consumption per 100km	≤50 L
Main Performance
Tail swing radius of superstructure	4.385m
Boom section	5
Boom shape	U-shaped
Max. lifting moment-Base boom	3293kN.m
Max. lifting moment-Full-extend boom	1803kN.m
Max. lifting moment-Full-extend boom+jib	993kN.m
Length-Base boom	12.96m
Length-Full-extend boom	50m
Length-Full-extend boom+jib	67.5m
Outrigger span(Longitudinal/Transversal)	6.43×8m
Jib offset	0°15°30°
Working Speed
Max. single rope lifting speed of main winch(no load)	130m/min
Max. single rope lifting speed of auxiliary winch(no load)	130m/min
Full extend/retract time of boom	140s/170s
Full raise/lower time of boom	70s/90s
Swing speed	0~1.8 r/min
