• Model NO.：SAC2200S
• Shaft Number：8
• Crane Jib：108m
• Type：Straight Arm
• Transport Package：Roro,Container
• Specification：Max Lifting Capacity: 220 t
• Origin：China
• HS Code：87051091
• Production Capacity：500,Month

Basic Info.

Model NO. SAC2200S Shaft Number 8 Crane Jib 108m Type Straight Arm Transport Package Roro/Container Specification Max Lifting Capacity: 220 t Origin China HS Code 87051091 Production Capacity 500/Month

Product Description

New SAC2200S 220t 200 Ton Hydraulic Crane All-terrain Crane 10% Discount
All Terrain Crane 220 Tons Lifting Capacity

Max. Lifting Capacity: 220 t
Max. Boom Length: 68 m
Max. Lifting Height: 105 m
Basic performance

1. Key structural components are optimized with the lifting capacity leading the products of the same tonnage.
2. With the max. boom length of 68m and lifting height of 68.5m, it leads the industry.
3. Seven-section boom structure and the fully optimized U-shaped high-strength structural steel boom ensure the more uniform stress and lighter weight; mounting angles of jib are 0°, 20°and 40°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency.
4. Four-wheel drive and six steering modes improve the mobility; the min. turning radius of full-wheel steering is not greater than 10m to improve the trafficability and comfortableness under the complex road conditions.

Excellent quality

1. Stable and high-quality hydraulic components such as the main oil pump, main valve, winch motor, slewing motor and balance valve improve the system reliability; superior control performance is ensured through the accurate parameter matching.
2. The slewing system is equipped with an integrated slewing buffer valve with free slipping function, which allows for stable slewing and control and superior micro-mobility.
3. The crane instrument is integrated with an intelligently controlled integral electrical system, so that operating parameters can be controlled at any time, ensuring superior ride comfort; and meanwhile, the engine fault prompt function is provided to facilitate servicing and troubleshooting.
4. Control room consists of the safety glass and corrosion-resistant steel plate, and is configured with the softened interior trim; large interior space, panoramic sunroof, adjustable seats and other user-friendly designs as well as the air conditioning and electric wiper guarantee the more comfortable and easier operation.

Energy saving and environmental protection
Energy is saved through the hydraulic system load feedback, constant power control, dual variable-speed pump and motor.

Safe and reliable

1. The torque limiter calculation system is established based on the lifting model.  Through the on-line no-load calibration, the rated lifting accuracy is ±5%, providing the all-round protection for the lifting operation. When the overload operation is performed, the system automatically provides the alarm to safeguard the operation.
2. Hydraulic system is configured with the hydraulically balanced valve, overflow valve and two-way hydraulic lock etc., to ensure stable and reliable operation.
3. Main and auxiliary winches are equipped with three-wrap rope protector. Boom and jib ends are equipped with height limiters respectively to prevent the overfall and overwind of wire rope.
4. Length, angle and pressure sensors are configured to display the real-time operating status of crane, and automatically cut off the dangerous action and sound the buzzer.

GCP System

1. The remote monitoring and management system, the first of its kind in the country, has the strong acquisition function for operating conditions and parameters, and can implement the remote fault diagnosis and management.
2. Customers can monitor the operation of equipment, and query/order the accessories.
