• Model NO.：LH
• Type：Double Beam Crane
• Lifting Motor：S3 40%, Insulation Class F, IP65
• Motor (C.T L.T)：S3 60%, Insulation Class F, IP65
• Lift Speed：4,0.66 M,Min
• Cross Speed：5,20 M,Min, 2~20 M,Min
• Crane Traveling Speed：5,20 M,Min, 3~30 M,Min
• Limit Switch：All Direction Dual Limit Switch
• Control Method：Pendant Push Button, Remote Controller, Cabin
• Industrial Voltage：380V, 400V, 415V, 440V
• Duty Class：M3~M7
• Painting：Sand Blasting, Rust-Free Treatment to Steel Surfac
• Transport Package：Wooden Box, Plywood
• Specification：CE, ISO
• Trademark：LYFOO
• Origin：Xinxiang, Henan, China
• HS Code：84261120
• Production Capacity：2000 Per Year

Capacity3t ~ 50tWorking SpanUp to 31.5mLift heightUpon to be requestedLifting Speed8m/minCross Travel Speed20m/minTrolley Travel Speed20m/minWork DutyA5Controlled byPendant/RadioPower Supply380v, 3p, 50hz
Technical Characteristics:
1) Hard-tooth surface of reducer
2) Steel winding drum
3) Imported rope
4) Converter function of adjustable speed without contact or module
5) Intelligence controlling
6) Trinity drive

Cause this is a customized product, please provide us the following information
Capacity?
Lifting Height? (from hook to the ground)
Span?
Local Power-V-Hz-P?
