Top Brand Zoomlion 16 Ton Mobile Tower Crane Tc7035b-16
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：50-100m
- Maximum Lifting Weight：>10t
- Installation：Assembled
- Moving Type：Fixed
Base Info
- Model NO.：TC7035B-16
- Type：Top-Slewing Crane
- Jib Length：60 M
- Transport Package：Comply with Export Packaging Requirements for Min
- Specification：CE
- Trademark：ZOOMLION
- Origin：China
- HS Code：84262000
- Production Capacity：100 Units Per Month
Description
Rated lifting moment (kN.m) 3150 Max. lifting height (m) Free-standing stationary crane61.5Anchored crane241.5Working radius (m) Max. working radius 70Min. working radius 3.75Max. lifting capacity (t) 16 Rope fall α=2 α=4Hoisting mechanism Speed (m/min) 37.57518.7537.5Lifting weight (t) 84168Power (kW) 60/60Slewing mechanismSpeed (m/min) 0~0.6Power (kW) 2×7.5Trolleying mechanism Speed (r/min) 0~100Power (kW) 11
