• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Straight Arm
• Warranty Time：24 Month
• Working Condition：in Good Condition
• Transport Package：Nude,Container,Roro,Bulk
• Specification：130cubic meters
• Origin：China
• Production Capacity：50peices,Quarter

Total weight in travelkg54900   52400Axle 1kg7500    7500Axle 2kg7500    7500Axle 3kg8300    10000Axle 4kg12000    12500Axle 5kg12000    12500Power  Engine rated powerkW/(r/min)360/1800 (306/1900)Engine rated torqueN.m/(r/min)2200/1300 (2010/1200)Engine rated speedr/min1800 (1900)Min. ground clearancemm310Travel  Approach angle°20Departure angle°14Braking distance (at 30km/h)m≤10Max. grade ability%40Min. turning diameterm24Fuel consumption for 100kmL70Main performanceMax. rated total lifting capacitym100Min. rated working radius 3Turning radius at turntable tail  Counterweightmm4200Aux. winchmm4590Max. lifting torque 3450Base boomkN.m3450(4m×88t)Fully extended boomkN.m1950(24m×7.1t)Fully extended boom+ jibkN.m1230(19.2m×6t)Outrigger span (full extension)  Longitudinalm7.56Lateralm7.6Lifting height  Base boomm13.5Fully extended boomm50.9Fully extended boom+ jibm70.4Boom lengthm13.5Fully extended boomm51Fully extended boom+ jibm51+18.1+4Working speed  Jib setting angle°0,15,30Boom luffing times75Boom  Boom telescoping time  Full extensions180Max. swing speedr/min2Outrigger extension/retraction time  Outrigger beam in extension/retractions28/45Outrigger jack in extension/retractions50/80DimensionUnit Overall lengthmm13650Overall widthmm2500Overall heightmm3380Weight  Total weight in travelkg29400Front axle loadkg6200Rear axle loadkg23200Power  Engine model SC8DK280Q3 / WD615.329(domestic III)Engine rated powerkW/(r/min)206/2200   213/2200Engine rated torqueN.m/(r/min)1112/1400  1160/1400Travel  Max. travel speedkm/h75Min. turning diameterm21.5Min. ground clearancemm275Approach angle°16Departure angle°13Max. grade ability%30Fuel consumption for 100kmL≈37Main performance  Max. rated total lifting capacityt25Min. rated working radiusmm3000Turning radius at turntable tailm3.065Max. lifting torquekN.m1010Base boomm10.7Fully extended boomm34.19Fully extended boom+jibm42.15Longitudinal outrigger spanm5.14Lateral outrigger spanm6Working speed  Boom luffing times75Boom full extension times100Max. swing speedr/min≥2.5Max. speed of main winch (single rope)m/min≥120Max. speed of aux. winch (single rope)m/min≥12
