Double Box Beam Gantry Crane, Heavy Duty Crane

Lyfoo Industry Co., Ltd.
  • Certification：CE, ISO9001
  • Condition：New
  • Maximum Lifting Weight：>200t
  • Maximum Lifting Height：15-20m
  • Operation Form：Air Operation+Ground Operation
  • Type：Container Gantry Crane

Base Info

  • Model NO.：MG
  • Main Girder Form：Double Girder
  • Capacity：10-500t
  • Power Supply：380V,400,415,440V 50,60Hz 3pH
  • Span：10-55m
  • Maxinum Lifting Height：18.5m
  • Hoist Lift Speed：0.8,8 M,Min
  • Cross Speed：20 M,Min
  • Long Travel Speed：20 M,Min, 5,20 M,Min
  • Stepless Speed Control：Available (Variable Frequency Control)
  • Electrical System Brand：Siemens,Schneider,Chint
  • Affiliate Documents：English Operation Manual, Wiring Diagram
  • Transport Package：Strong Wooden Box
  • Specification：Mg
  • Trademark：LYFOO
  • Origin：China
  • HS Code：84261930

Description

Capacity/t10/3.2 16/3.2 20/5 32/5 50/10 80/20 100/50 125/30 160/30Span/m22  26  30  35  40Power SupplyThree Phrase Alternating Current
Features:
1) Widely used outside and windy area.
2) MID and heavy duty type
3) Stronger structure
4) Safe traveling
5) Fluent starting and stopping
6) Noise-less
7) Good appearance
8) Easy and convenient maintenance
9) Cost effective
10) CE certification

Advantages:
1. The quality of the main girder decides use age and use cost of the crane. "shengqi" consummately adopt European most advanced design and manufacture craft of the main girder. Mail girder wear well , not only let user ease use, but also low maintenance cost.

2. The up camber curve of main girder adopt optimize 4 times curve, ensure traveling have no upgrade resistance when full loading. Overcome the disfigurement of traveling motor overload traveling and trolley slide traveling.

3. End carriage is box girder, and the connection between end carriage and main girder adopt high strength bolt, in order to transport conveniently.

4. Optimize structure design, bearing layout reasonable , bear horizontal force, improve use age of the bearing.

5. The connections of every mechanical part are gears, in order to achieve simple installation and convenient maintenance. The drive wheel group and driven wheel group are all supported on crescent bearing box , convenient for disassembly and adjust.

please contact us with following information
1. The capacity
2, The lifting height( from thr fround to the hook center).
3. the span (width of the crane you need)
More detailed information will help us to prepare the solution. anything you have question,please feel free to contact us.
