| Model | XGC55 | XGC75 | XGC85 | XGC100 |
| Performance parameters |
| Max. basic boom rated lifting capacity (t) | 55 | 75 | 85 | 100 |
| Max. fixed jib rated lifting capacity (t) | 11.4 | 12 | 12 | 15.6 |
| Max. luffing jib rated lifting capacity (t) | - | - | - | - |
| Max. load moment (t.m) | 203.5 | 286 | 341 | 580.3 |
| Tower jib lifting capacity (t) | - | - | - | - |
| Max. boom single top-rated lifting capacity (t) | 6 | 6.5 | 8 | 12.5 |
| Dimensions |
| Basic boom length (m) | 13~52 | 13~58 | 13~58 | 19~73 |
| Boom elevating angle (°) | -3~80° | -3~80 | -3~80 | 30~81 |
| Fixed jib (m) | 7~16 | 7~19 | 7~19 | 13~25 |
| Elevating boom (m) | - | - | - | - |
| Max. dimension of single unit in travel configuration L*M*H (m) | 12.04×3.45×3.36 | 12.7×3.4×3.4 | 13.05×3.4×3.3 | 10.5×3.0×3.25 |
| Fixed jib angle (°) | 10, 30 | 10, 30 | 10, 30 | 15, 30 |
| Fixed jib length (m) | - | - | - | - |
| Speed |
| Winch mechanism max. single speed (m/min) | 125 | 128 | 120 | 110 |
| Boom elevating mechanism max. single speed (m/min) | 87 | 70 | 70 | 75.6 |
| Fixed jib elevating mechanism max. single speed (m/min) | - | - | - | - |
| Max. slewing speed (km/h) | 2.4 | 3 | 2 | 1.8 |
| Max. traveling speed (km/h) | 1.3 | 1.4 | 0.9 | 1.3 |
| Max. grade ability (%) | 30 | 30 | 30 | 0.3 |
| Average ground pressure | 0.06 | 0.08 | 0.087 | 0.087 |
| Fixed jib elevating mechanism max. single speed (m/min) | - | - | - | - |
| Engine |
| Engine model | SC7H210 | SC7H210 | SC9D272 | SC9DK270 |
| Engine rated output (kw) | 155 | 155 | 200 | 200 |
| Emission standard | Weight |
| Operating weight | 46.1 | 61 | 71.5 | 104.5 |
| Max. mass of single unit in travel configuration (t) | 28.6 | 37 | 41.2 | 30.9 |
