• Model NO.：ZTC800V
• Shaft Number：4
• Crane Jib：Five-Arm
• Type：Straight Arm
• Max. Rated Lifting Weight：80 Ton
• Engine：Imported Engine
• Max. Load Moment of Basic Boom：2940 mm
• Max. Lifting Height of Basic Boom：13.2 M
• Max. Lifting Height of Main Boom：47.2 M
• Max. Lifting Height of Fly Jib：58.3 M
• Max. Gradeability：38%
• Max. Traveling Speed：75 Km,H
• Model：Ztc8000V
• Transport Package：Nude Packing
• Specification：ISO
• Trademark：Zoomlion
• Origin：Hunan, China
• HS Code：87051092
• Production Capacity：5000sets,Month

ItemValueRemarksWorking performance specificationMax. rated total lifting capacity  kg80000 Max. load moment of basic boom  kN.m29401470(Outrigger beam half extended)Max. load moment with max. main boom length kN.m1440793.8(Outrigger beam half extended)Max. lifting height of basic boom m13.2 Max. lifting height of main boom m47.2Deformation of boom is not taken into considerationMax. lifting height of fly jib m58.3Working speedMax. speed of single rope on main winch m/min130The 4 th  layer of drumMax. speed of single rope onauxiliary winch  m/min110The 2 nd  layer of drumDerricking time of boom  s70 Telescopic time of boom  s140 Slewing speed  r/min0~2.2 Traveling specificationMax. traveling speed  km/h75 Max. gradeability  %38 Min. turning circle diameter  m≤24 Min. ground clearance  mm270Comply with related standardsLimits for exhaust pollutants and smokeComply with related standardsGB3847-2005
GB17691-2005
(StageIII)Oil consumption per hundred kilometers L52 Mass specificationDeadweight of crane in traveling condition kg50000 Complete vehicle kerb mass kg49870 Front axle load  kg24000 Rear axle load kg26000 Dimension specificationOverall dimensions(L×W×H)mm
 mm14600×2800×3800 Base on outriggers m6.20 Main boom length m12.1~46.5 Main boom angle°-2~80 Fly jib length m10.3~17.5 Offset angle of fly jib °0 , 30
