L Type Single Girder Electric Trolley Gantry Crane
Henan Kuangshan Crane Co., Ltd.- Certification：CE, ISO9001, ISO9001: 2000, Ce, GOST SGS
- Condition：New
- Maximum Lifting Weight：<20t
- Maximum Lifting Height：<10m
- Operation Form：Ground Operation
- Type：Gantry Crane
Base Info
- Model NO.：L Model
- Main Girder Form：Single Girder
- Lifting Height：10m
- Working Duty：A5
- Lifting Device：Electric Trolley
- Working Environment temperature：-20~40 Degree
- Trolley Quantity：One or Two( on Your Option)
- Crane Reducer：Hydraulic Big Transmission Brake
- Control Methods：Cabin or Remote Control
- Application：Mineral, Workshop, Container, Construction
- Sling Type：Wire Rope
- Power Source：Electric
- Transport Package：Chinese Standard
- Specification：ISO,SGS
- Trademark：KUANGYUAN
- Origin：Xinxiang China
- HS Code：84261930
- Production Capacity：500 Sets, Month
Description
Lifting Capacityt 5 10 16/3.2 20/5.0 32/5.0 Span m 18, 22, 26, 30, 35 Lifting Height Main Hook m 10; 11 10; 11 10; 11 10; 11 10; 11 Aux Hook 10.5; 11.5 10; 11 10.85; 11.85 Working grade A5 Speed Hoisting Main Hook m/min 12.75 9.82 9.7 9.2 7.6 Aux Hook 22.5 19.4 19.5 Trolley Travelling 37.5 39.7 39.7 39.7 38.9 Crane Travelling 46.3, 40 39.5; 40 40, 47.1 40, 47 38.9, 44.1 Trolley Weight t 2.95 4.27 8.4 8.8 13.1 Max. Wheel Pressure KN 160-233 225-298 298-383 340-432 530-690 Steel Rail recommended P43 (43kg/m) Power Source 380V, 50HZ, 3 Phase (or according to your demands. )
