• Model NO.：LDA
• Maximum Lifting Weight：<20t
• Main Girder Form：Single Girder
• Type：Ordinary
• Product Name：Single Beam Eot Crane 10 Ton with Wire Rope Electr
• Power Supply：3AC 220V~480V 50,60Hz
• Lifting Speed：4,0.66 M,Min
• Cross Travelling Speed：20,5 M,Min
• Crane Travelling Speed：20,5 M,Min
• Working Class：A5
• Lifting Mechanism：Wire Rope Electric Hoist
• Similar Model：Ldp,Ldc,Lb,Lz
• Recommended Rail Width：37~70mm
• Lifting Height：6,9,12,18,24,30m
• Transport Package：Standard Export Package
• Specification：6 ton
• Trademark：NYBON
• Origin：Henan
• HS Code：84261120
• Production Capacity：100sets , Month

Capacity

t

1,2,3,5,10

16,20

Span

m

                               7.5-22.5

Lifting height

m

6,9,12,18,24,30

12,18,24,30

Speed

Lifting

m/min

5/0.8

4/0.64

Cross travel

m/min

20/5

20/5

Long travel

m/min

20/5

Electric hoist

type

ND

ND

Working duty

A5

A5

Power supply

AC

3AC  220~480V 50/60Hz

3AC  220~480V 50/60Hz

1. Q: What's your MOQ?

  A: 1 Set;

2. Q: What's your package?

  A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;

3. Q: What's your delivery period?

  A: Within 10/25/40 days after your prepayment received; exact period should be based on detailed requirements and actual period;

4. Q: What's your warranty period?

  A: 12 months from winches accepted;

5. Q: Do you have engineer oversea installation service?

   A: Yes; We have;

6. Q: What kinds of products do you have?

    A: All kinds of industrial electric winch (especially non-standard); Overhead Crane; Gantry Crane, Electric Hoist; Screw Hoist;
Radial/Flat Gate Hoist; Steel Gate; etc.

7. Q: Do you provide lift tools?

    A: Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet , pulley blocks, hook, lock catch, wire
rope, fiber rope, etc.

8. Q: Could your winches drag inclined?

    A: Yeah, our electric winches could drag horizontal, drag inclined, hoisting vertical.
