• Model NO.：QY150V633
• Type：Bridge Crane
• Payload：75ton
• Brand：S Any
• Application：Construction Usage, Workshop Usage
• Power Source：Hydraulic
• Sling Type：Cable
• Transport Package：Nude Package
• Specification：CE
• Trademark：S ANY
• Origin：China
• Production Capacity：50 Sets,Month

Maximum  lifting weight12tMaximum lifting height33-40mLifting arm5m*8
6m*8Leg span6.5*6.1/6.5*6.5mTelescopic frame1.5MOutline dimension8*2.15*3m
8.90*2.15*3mMotor power15KWHoisting speed80/60m/minSlew rate0-3r/minEngine type4102#Engine power51kwTire model825-20Max Travel speed60km/hWheelbase2.8/3.1m
The small crane turntable due to material porosity or interlayer, the raceway hardness of hardened layer depth, swim uneven manufacturing quality problems or some external reasons caused by raceway spalling or hardened gear tooth broken, will enable the small crane is not working properly.
For the raceway peeling layer, we must first make a correct judgment. Peeling occurs, generally not easy to see in the outside. According to our experience, south the following conditions, that is: the host raceway delamination with load rotation, raceway "Ker - Ker" noise, rotation speed uneven or a range of speed slowed down and accompanied by a slight vibration; rotary speed reducer machine temperature is too high or too large current; the rotary gear reducer and hydraulic coupling or coupling the keyway is squeezed bad etc..
After peeling, must be repaired in time. Otherwise, the area will be expanded, so that the entire small crane turntable scrapped.
Repair method is: first small crane turntable in the roller or ball out, the inner and outer ring raceway and separation; gasoline to clean; then with grinder (wheel) will be carefully around the crack has occurred in the hardened layer of abrasion, delamination will bottom smooth; the welding and cutting torch raceway supplement weld preheating, welding used in carbon steel electrode (electrode must be used before drying, and with baking with), to make the welding layer is slightly higher than the raceway surface of 1-2mm; if the delamination depth or larger, should be layered and segmented welding, do not make the parent material caused by high temperature deformation; this prevents rapid cooling welding cracks, after welding should immediately take insulation measures, so that he gradually cooling. After cooling with grinder grinding welding layer, making it slightly higher than the raceway surface, using an oilstone or emery cloth grinding metallographic gradually repair welding layer, making it highly consistent with normal raceway surface, with the corresponding original curvature detection model, until qualified; cleaning with gasoline raceway and roller (steel ball). Lubricating grease, assembling can be completed.
The repair method is local welding or insert repair method, local welding is: first the residual matrix crack damaged parts by hand wheel grinding, gasoline (oil) to clean the torch for this position; preheating, when reaches a certain temperature, using carbon steel electrode in wheel tooth damaged parts push welding the teeth of the prototype, which is 1-2mm higher than the party tooth surface; send experienced benchwork, according to profile template detection, until the tooth shape to meet the requirements so far.
When a small crane turntable of the tooth is damaged, can be cut along the root, then the root file into shape. On the same kind of waste gear ring, the next tooth is cut and processed into the corresponding shape of the base metal. In order to ensure the consistency of tooth distance, and use double screw chuck value-added tight after welding of low carbon steel in the teeth around. Finally, with a file and other tools to ensure weld flattening, meshing augmentation can be.
Item
Specification
Remarks
Working performance
Max. rated lifting capacitykg
150000
Max. lifting torque of basic boomkN.m
5292
Radius: 6m
Max. lifting torque of Max. length boom
kN.m
2264
Radius: 22m
Max. lifting height of basic boomm
13.5
Max. lifting height of boomm
60
The specifications do not include deflection of boom and jib.
The specification in the brackets includes the length of extension.
Max. lifting height of jib m
78.4 / (86)
Working speeds
Max. hoist rope speed (Main winch) m/min
110
Drum 5th layer
Max. hoist rope speed (Auxiliary winch)
m/min
75
Drum 3rd layer
Boom derricking time s
78
Boom extending timemin
12
Max. slewing speedr/min
1.5
Traveling specifications
Max. traveling speedkm/h
72
Max. gradeability%
40
Min. turning radiusm
23
Min. ground clearancemm
280
Limit for exhaust pollutants and smoke
Conform to related standards.
Conform to
GB3847-2005
GB17691-2005
(National StageIII)
Oil consumption per hundred kilometers
L
80
Weights
Self weight in traveling conditionkg
54900
Complete vehicle kerb masskg
54705
Axle load (axle 1, 2, 3)kg
8700/8700/8700/
Axle load (axle 4,5,6)kg
20800(2 axles)/8000
Dimensions
Overall dimensions(L×W×H)mm
14950×3000×3950
Longitudinal distance between outriggers
m
7.04
Transversal distance between outriggers
m
8.5(Fully extended),
6.5(Half extended)
Boom lengthm
13~59
Boom angle°
-1.5~82
Jib lengthm
11 ,18.6
Offset°
0 , 30
Chassis
Model
ZLJ5663
Code: ZLJ5663V3
Type
II
Engine
Model
OM502LA
Rated powerkW/r/min
390/1800
Max. torqueN.m/r/min
2400/1080
