150 Ton 150t Xgc150 Crawler Crane

Evangel Industrial (Shanghai) Co., Ltd.
  • Max. Lifting Height：76
  • Rated Loading Capacity：150t
  • Certification：ISO9001, CE
  • Condition：New
  • Warranty：1 Year
  • Longest Boom + Jib：43 + 15.25

Base Info

  • Model NO.：XGC150
  • Engine Model：Qsb5.9-C210 5.9
  • Rated Power/Revolution Speed：154,2200 Kw, Rpm
  • Boom Length：13-52m
  • Swing Speed：0-1.9
  • Transport Package：Regular Package
  • Specification：12200*3000*3300kg
  • Origin：China
  • Production Capacity：50

Description

ItemsUnitDataBasic boomT150Fixed jibT24Max. load momentt/m927.4Boom lengthM18-81Boom working condition   .30-80Fixed jib working condition.30-80Fixed jib lengthM13-31Winch mechanism max single line speed(no load, at 5th layer)m/min110Boom elevating mechanism max. single line speed(no load, at 1st layer)m/min2×32Max rope single line pullT13.5Wire rope diamMm26Max slewing speedr/min1.5Max traveling speedKm/h1.3Grade ability%30Average ground pressureMpa0.102Engine powerKw235Mass of the vehicle as a whole( including main hook block and 19m boom)T154Max mass of single unit in travel configuration 37Max dimension of single unit in travel configuration(L×W×H)t11.0×3.0×3.3
