• Model NO.：SRC250
• Shaft Number：2
• Crane Jib：Four-Arm
• Type：Straight Arm
• Max. Rated Lifting Capacity：25t
• Min. Rated Range：3.05m
• Tail Slewing Radius of Swingtable：3.8m
• Boom Section：4
• Boom Shape：U-Shaped
• Full-Extended Boom：31.5m
• Full-Extended Boom+Jib：45.2m
• Outrigger Span (Longitudinal X Transvers：6700 X 6500 mm
• Jib Offset：0° 15° 30°
• Max. Single Rope Lifting Speed of Main W：125 M,Min
• Transport Package：Nude Package, Suitable for Shipment
• Specification：25 ton
• Origin：Hunan, China
• HS Code：8426411000
• Production Capacity：1000 Units,Month

Dimensions and Weight   Overall length11740 mmOverall width2620 mmOverall height3600 mmAxle distance2940 mm Overall weight27400 kgLoad of front axle
Load of rear axle13700 kg
13700 kg Crane Carrier Model of engine
 Cu m-mins ISDe210-30 Tier 3Rated engine power
 209/154/2200
hp/kw/rpmMax. engine torque800 N.m/1400 rpmMax. travelling speed40 km/h Working fuel consumption per hour10 l/hTurning radius5500 mmWheel formula4×4Min. ground clearance350 mmApproach angle18.6°Departure angle17.2°Max. gradeability55%Standard toolboxincludedFire extinguisherincludedHeating system in cabincluded Crane Superstructure Max. rated lifting capacity25 tMin. rated range3.05 mTail slewing radius of swingtable3.8 m Boom section4Boom shapeU-shapedMax. lifting moment                                                                                   96.8 t.mBoom length                                                Base boom
                                                                     Full-extended boom
                                                                     Full-extended boom+jib9.9 m
31.5 m
45.2 mOutrigger span (Longitudinal x Transversal)6700 x 6500 mm Jib offset0° 15° 30°Max. single rope lifting speed of main winch (no load)125 m/minMax. single rope lifting speed of auxiliary winch (no load)126 m/minFull extension/retraction time to boom65/40 sFull lifting/descending time to boom45/60sSlewing speed2.5 r/minTemperature range-25°C till +40°CHigh Voltage Detectorincluded
