• Model NO.：RT120U
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Straight Arm
• Weight：76830kg
• Max.Travel Speed：23km,H
• Min.Turning Diameter：7.5m
• Min.Ground Clearance：568mm
• Max.Gradeability：60%
• Base Boom：12.4m
• Transport Package：Nude
• Specification：14900*3500*3990mm
• Trademark：NEWINDU
• Origin：China
• Production Capacity：1000units,Per Year

Detailed PhotosProduct ParametersItem  UnitDimensionsOverall length14900mmOverall width3500mmOverall height3990mmWeighetDead weight in travel state76830kg1st axle41710kg2nd axle35120kgPowerengine modelQSL8.9 engine rated output224/2100KW/(r/min)engine rated torque1369/1500N.m/(r/min)TravelMax.travel speed≥33km/hMin.turning diameter≤7.5mMin.ground clearance568mmApproch angle21.1°Departure angle17.3°Max.gradeability≥60%Lifting PerformanceMax.total rated lifting load100tMin.rated working radius3mTurning radius at swing table tail4930mmBase boom amx.load moment3500kn.mBase boom12.4mFull-extended boom48mFull-extended boom+Jib68.6mOutrigger longitudinal distance span8.4mOutrigger lateral distance span8.2/6.0mWorking speedBoom elevating time≤95sBoom telescoping time≤150sMax.swing speed≥2.0r/minMain winch max. speed(on load)≥125m/minAuxiliary winch max. speed(on load)≥125m/minPackaging & Shipping
