• Model NO.：ZTC1000V653
• Type：Folding
• Max. Lifting Height of Basic Boom：14.0
• Max. Lifting Height of Main Boom：64.0
• Max. Gradeability：40
• Main Boom Length：13.5~63.0
• Transport Package：RO-RO,Bulk,Container
• Specification：14100*2750*3750
• Trademark：Zoomlion
• Origin：China
• HS Code：84294019
• Production Capacity：1000 Set Per Month

Work performanceMax. rated lifting capacity              kg10000Max. load moment of basic boom           kN.m4000Max. load moment of main boom (fully extended) kN.m1860Max. lifting height of basic boom        m14.0 Max. lifting height of main boom         m64.0 Max. lifting height of jib               m82.5 / (90.5)WorkMax. hoist rope speed (Main winch)       m/min.110speedsMax. hoist rope speed (Auxiliary winch)  m/min.75 Boom derricking up time                  s70 Boom extending time                      s13 Max. slewing speed                       r/min.1.5DrivingMax. height above sea level              m2000Max. driving speed                       km/h75Max. gradeability                        %40Min. turning diameter                    m≤23Min. ground clearance                    mm300Limits for exhaust pollutants and smokeConform to related standardsFuel consumption per hundred kilometers  L70MassDeadweight in driving condition          kg58400Complete vehicle kerb mass               kg58205Load on axles 1 and 2                    kg10800/10800Load on axles 4 and 5                    kg26000(dual-axle)/10800DimensionsOverall dimensions (L × W × H)         mm15400×3000×3950Outrigger spread (L)                     m8.05Outrigger spread (W)                     m7.6 (fully extended),5.4 (intermediately extended)Main boom length                         m13.5~63.0Boom angle                               °-0.5~82Jib length                               m11 ,18.6Jib + extension length                   m26.6Offset                                   °0 ,30

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

       Oriemac is a leading Chinese construction machinery exporter, located in Shanghai, and has introduced top Chinese machinery enterprises and their products to international markets, such as Zoomlion, , Changlin, liugong, Shantui, HBXG,etc.

      Oriemac brings you a wide range of construction machionery series as follows:

-- Lifting Machinery, such as Truck Crane, All Terrain Crane, Rough Terrain Crane, Crawler Crane, and mTruck-mounted Crane
-- Earthmoving Machinery, such as Wheel loader, Mini Loader, Excavator, Bulldozer, Backhoe Loader, and Skid Steer Loader
-- Concrete Machinery, such as Concrete Pump, Trailer-mounted Concrete Pump and Concrete Mixer
-- Drilling Machinery, such as Horizontal Directional Drill, Rotary Drilling Rig and Roadheader
-- Logistics Machinery, such as Telescopic Handler and Forklift
-- Special Vehicle, such as Dump Truck, Semi Trailer, Aerial Work Form, and Fire Truck Our company will offer you the high quality products with a low price, quick delivery, and professional after-sale services.
