Top Crane Machine 55 Ton Crawler Crane Quy55
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Online Service
- Max. Lifting Height：One Warranty
- Rated Loading Capacity：55ton
- Certification：CE
- Condition：New
- Warranty：1 Year
Base Info
- Model NO.：QUY55
- Rated Loading Capacitys：55ton
- Engine Power：153kw
- Maximum Lifting Capacity *Radius：52m
- Transport Package：Bulk Cargo ,RO-RO
- Specification：55ton
- Trademark：china top
- Origin：China
- HS Code：8426200000
- Production Capacity：100pieces,Month
Description
Item
Value
Remarks
Max. lifting capacity × Radiust × m
70×3.8
Deadweight with basic boomt
61
Main boom lengthm
12~57
Fixed jib lengthm
6~18
Max. lifting capacity of fixed jibt
6.4
Offset angle of fixed jib°
10,30
Max. length of main boom with fixed jib m
42+18
Max. speed of single rope on drum
Main winchm/min
120
The 4 Slewing speedrpm
0~2.4
Traveling speedkm/h
0~1.35
Gradeability%
30
Ground pressureMPa
0.074
Overall dimensions (L×W×H)m
11.2×3.3×3.2
Incl. mast, boom bottom section
Engine
Rated power/ rotational speed
kW/rpm
153/2200
Max. output torque/ rotational speedNm/rpm
929/1300
Emission standard
TIER 3
Crawler gauge × ground contact length × track shoe widthmm
2540×5040×1000
Crawler carrier retracted
4000×5040×1000
