• Model NO.：QY25B. 5
• Shaft Number：3
• Type：Small Crane
• Rated Loading Capacity：25ton
• Engine Model：Sc8dk260q3
• Engine Output：192kw
• Dimension：12400*2500*3320mm
• Power Source：Hydraulic
• Sling Type：Chain
• Transport Package：Suitable Package for Shipment
• Specification：ISO
• Origin：Jiangsu, China
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. QY25B. 5 Shaft Number 3 Type Small Crane Rated Loading Capacity 25ton Engine Model Sc8dk260q3 Engine Output 192kw Dimension 12400*2500*3320mm Power Source Hydraulic Sling Type Chain Transport Package Suitable Package for Shipment Specification ISO Origin Jiangsu, China Production Capacity 100 Sets/Month

Product Description

Features-  QY25B. 5 Truck Crane

More excellent performance
The optimizing layout of the machine makes the stress of the main bearing carriers more reasonable, and the lifting performance is higher than the products with the same tonnage.
Apply the mature jib technique which integrates plug-in boom head, embedded boom block, and special telescoping mechanism, which makes the jib more stable and reliable.
Optimize the stress design. Adopt the box-type outriggers which have larger span, stronger rigidity, and better stability.
More reliable quality
Adopt the classic K series jib telescoping technique, working safer and more reliable.
Make the most complete safety device system in the industry, ensuring the lifting safer and more reliable.
The comprehensively upgraded brake system adopts double circuit air pressure design. Multiple systems ensure the brake safety of the truck during travel.
The new power steering mechanism adopts hydraulic power design, which makes the steering light, flexible, and precise, and ensures the safety of the truck.
The intensity and rigidity of the rotary table and frame structure with high rigidity are completely coordinated.
The perfect integration of the design and structure realizes the automation of welding, which is more reliable.
Easier to operate
The high efficient and energy efficient load sensing hydraulic system is sensitive to operate and precise to control, having good slight mobility.
Optimize the control levers, which is easier to operate.
The cab adopts orthodrome front windscreen, having wider operating views.
Easier to maintain
The optimizing design of the pipeline traces makes the layout more scientific and reasonable, greatly reducing the dismantling and installing time of the pipelines and the maintenance expense.
Completely upgrade the electrical system. Adopt anti-creep connector clips, greatly prolonging the service life of the parts.
Adopt K series rope anti-disorder technique, improving the lifting efficiency, reducing the labor intensity, and prolonging the service life of the steel rope.
The telescoping steel wire rope oriented and protective device avoids the steel wire rope out of the track and broken.
Fully covered walking plate supplies a platform for the maintenance, and effectively protects the parts of the machine.
More energy-efficient and environmental friendly
Adopt double industrial automation control engine, featuring strong power and energy efficiency.
Under the economical mode, it can meet the engine power requirement of the normal lifting work. Under the high power mode, it can meet the requirement of the high challenge and high efficient lifting work.
Adopt the high power radiator, avoiding the system from bad cooling, solving the problem of oil overheating, and prolonging the service life of the hydraulic oil.
Adopt the advanced matching technique, which makes the design more scientific. It can reduce the consumption of the mechanism, prolong the service life of the machine, and has high residual value.

Dimension	Unit	QY25B.5
Overall length	mm	12990
Overall width	mm	2500
Overall height	mm	3430
Weight
Total weight in travel	kg	29000
Front axle load	kg	6970
Rear axle load	kg	22030
Power
Engine model		SC8DK260Q3
Engine rated power	kW/(r/min)	192/2200
Engine rated torque	N.m/(r/min)	1000/1400
Travel
Max. travel speed	km/h	75
Min. turning diameter	m	20
Min. ground clearance	mm	272
Approach angle	°	16
Departure angle	°	13
Max. grade ability	%	30
Fuel consumption for 100km	L	40
Main performance
Max. rated total lifting capacity	t	25
Min. rated working radius	mm	3000
Turning radius at turntable tail	m	3.450
Max. lifting torque	kN.m	1010
Base boom	m	10.85
Fully extended boom	m	34.19
Fully extended boom+jib	m	42.3
Longitudinal outrigger span	m	5
Lateral outrigger span	m	6
Working speed
Boom luffing time	s	75
Boom full extension time	s	100
Max. swing speed	r/min	3
Max. speed of main winch (single rope)	m/min	120
Max. speed of aux. winch (single rope)	m/min	120
