CE Approval Good Quality Crawler Crane Factory Price
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Video Technical Support, Online Support
- Max. Lifting Height：50m
- Rated Loading Capacity：75ton
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
Base Info
- Model NO.：QUY75
- Max. Grade-Ability：30%
- Power：200kw
- Max Traveling Speed：1.0km,H
- Boom Length：58m
- Transport Package：Nude
- Specification：8225*3016*3515mm
- Trademark：NEWINDU
- Origin：China
- Production Capacity：1000units,Per Year
Description
Overview
Product DescriptionUnit Parameter Max.rated lifting capacity Basic boom t 70 Fixed jib t 6.5 Max. load moment kN-m 2744 Main boom length m 13-58 Main boom Luffing angle ° 30-80 Fixed jib length m 9-18 Winch max. single line speed( no load,at 5th layer) m/min 120 Boom luffing gear max. single line speed( at 1th layer) m/min 57 Max. swing speed r/min 2.4 Max. travel speed km/h 1.2 Max. grade-ability % 30 Mean ground pressure MPa 0.087 Engine output power kW 200 Gross vehicle mass (including main hook block and 13m boom) t 61 Max. weight of single unit in travel configuration t 39 Max. dimension of single unit in travel configuration (L×W×H) m 12.6×3.32×3.23
Detailed PhotosProduct ParametersItem
