Construction XCMG 50 Ton Hydraulic Mobile Truck Crane (QY50KA)
Xuzhou Construction Machinery Group Import & Export Co., Ltd.- Certification：GS, CE, ISO9001:2000
- Condition：New
- Maximum Lifting Height：42.15m
- Maximum Lifting Weight：50ton
- Shaft Number：3
- Crane Jib：Four-Arm
Base Info
- Model NO.：QY50KA
- Type：Folding
- Engine Rated Power：213kw
- Min. Turning Diameter：24m
- Transport Package：Comply with Export Packaging Requirment
- Specification：13930*2780*3630mm
- Trademark：XCMG
- Origin：Xuzhou, Jiangsu, China
- HS Code：87059091
- Production Capacity：10000,Year
Description
DescriptionUnit Parameter value Overall length mm 13930 Overall width mm 2780 Overall Height mm 3630 Axle base 1st ,2nd axle mm 1470 2nd ,3rd axle 4300 3rd ,4th axle 1350 Wheel Base mm 2304+2075 Front overhang/rear overhang mm 2389/2064or 2376/2064 Front extension/rear extension mm 2131/226 or 2144/226 Total vehicle mass in travel configuration kg 42200 Axle load Front axle kg 16200 Rear axle 26000 Engine Model WD615.338 Engine rated power kw/(r/min) 276/2200 Engine rated torque N.m/(r/min) 1500/1300-1600 Max. travel speed km/h 85 Min. steady travel speed km/h 2~3 Min. turning diameter m 24 Min. ground clearance mm 327 Max. grade ability % 42 Approach angle ° 19 Departure angle ° 15 Braking distance (at 30 km/h, full load ) m ≤10 Oil consumption per 100km L 40 Exterior noise level during acceleration traveling dB (A) ≤88 Noise level at seated position dB (A) ≤90
[Product Picture]
[Company Information]
[FAQ]
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted.
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC.
3: What about the delivery time?
A: 7-30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
