Heavy Duty Post Mounted Large Cantilever Jib Boom Crane 10t with Cheap Price
Nucleon (Xinxiang) Crane Co., Ltd.- After-sales Service：Technical Advisory of Installation & Commissioning
- Warranty：12 Months Warranty After Successful Installation
- Certification：CE, ISO9001, ISO14001
- Condition：New
- Application：Workshop, Warehouse
- Anchor：Whole-Buried
Base Info
- Model NO.：BZD
- Structure：Solid Web
- Material：Steel
- Type：Cantilever
- Load Capacity：up to 10 Ton
- Span：up to 9 Meters
- Height of Lift：up to 8 Meters
- Control：Radio Remote,Pendant Control
- Power Supply：380~480V, 50~60Hz, 3phase
- Hoisting Speed：5,0.8 M,Min (VFD as Option)
- Hoist Travel Speed：2~20 M,Min (VFD)
- Speed of Arm Rotate：0.5 M,Min
- Duty Class：A5 (ISO)
- Applications：Warehouse, Production Line, Machining Shop
- Lead Time：Within 30 Days
- Installation：Video Tutorial, Site Installation & Commissioning
- Random Files：Operation & Maintenance Manual, Wiring Diagram
- Spare Parts：Provide Random Spares for Two Year Maintenance
- Transport Package：Wooden Case, Waterproof Film
- Specification：360 Free Rotate,Rotate at Preset Loading Section
- Trademark：Nucleon Crane
- Origin：Henan, China
- HS Code：8426300000
- Production Capacity：200 Sets Per Annum
