Used Truck Cranes 15-20ton
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：30-40m
- Maximum Lifting Weight：>16t
- Shaft Number：3
- Crane Jib：Four-Arm
Base Info
- Type：Straight Arm
- Capacity：20-150 Ton Truck Crane
- Emission Standard：Euro 2,3,4,5
- Usage：Construction Lifting
- Overall Weight：46000kg
- Max. Traveling Speed：85km,H
- Length-Full-Extend Boom：99m
- Transport Package：Nude
- Specification：46000kg
- Origin：Hunan, China
- Production Capacity：100units,Week
Description
CapacityMax. lifting capacity160tDimensionsOverall length14750mmOverall width2750mmOverall height3850mmAxles3Axle distance-1,24325mmAxle distance-2,31350mmWeightOverall weight46000kgFront axle load6500kgRear axle load23500kgEngineModel Rated power213kW/2100rpmRated torque1050N·m/1200~1400rpmEmission standardEuro 3TravelingMax. traveling speed80 km/hMin.turning radius10 mMin.turning radius of boom head12 mDrive train6×4Min. ground clearance220mmApproach angle17 °Departure angle12 °Max. gradeability38%Fuel consumption per 100km≤ 37LMain PerformanceTemperature range- 30 ºC~ + 60 ºCMin.lifting radius3mTail swing radius of superstructure3.37mBoom section4Boom shapeU-shapedMax. lifting moment-Base boom962kN·mMax. lifting moment-Full-extend boom544kN·mMax. lifting moment-Full-extend boom+jib341kN·mLength-Base boom10.65mLength-Full-extend boom33.5mLength-Full-extend boom+jib41.5mOutrigger span(Longitudinal/Transversal)5.3m × 6.2mJib offset0 ° 15 ° 30 °Working SpeedMax. single rope lifting speed of main winch(no load)
≥120m/min
Max. single rope lifting speed of auxiliary winch(no load)≥120m/min
Full extend/retract time of boom70 / 50sFull raise/lower time of boom70 / 55sSwing speed0~2 r/min
