• Model NO.：Qy50KD
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Straight Arm
• Overall Length：13270mm
• Overall Width：2750mm
• Overall Height：3300mm
• Max. Travel Speed：66km,H
• Braking Distance：10m
• Engine Rated Output：206,2200kw,(R,Min)
• Colour：Golden
• Transport Package：Seaworthy Packing
• Specification：ISO, CE
• Trademark：Evangel
• Origin：China
• HS Code：87051091
• Production Capacity：1000sets,Months

ItemUnitParameterOutline dimensionOverall lengthmm13270Overall widthmm≤2750Overall heightmm3300Wheel baseAxle 1, Axle 2mm1520Axle 2, Axle 3mm3815Axle 3, Axle 4mm1350MassTotal mass in travel statekg39870Axle loadFront axlekg13935Rear axlekg25935Travel performanceTravel speedMax. travel speedkm/h66Min. stable travel speedkm/h3Turning diameterMin. turning diameterm24Min. turning diameter at boom tipm25Min. ground clearancemm275Approach angle(°)16Departure angle(°)10Braking distance (at 30km/h with full load)m10Max. grade-ability%37Fuel consumption for 100kmL48PowerModel WD615.67AEngine rated outputkW/(r/min.)206/2200Engine rated torqueN.m/(r/min.)1100/1400Engine rated speedrpm.2200
























 ItemUnitParameterLifting performanceMax. total rated lifting capacityt50Min. rated working radiusm3Turning radius at turntable tailm≤3.8Max. load momentBase boomkN.m1509Fully extended boomkN.m631Fully extended boom + JibkN.m441Outrigger spanLongitudinalm5.45Lateralm6.6Lifting heightBase boomm10.7Fully extended boomm40.1Fully extended boom + Jibm55.1
Working speedBoom raising times120Boom full extension times180Max. swing speedr/min2.0Hoist speedMain winchFull loadm/min≥70No loadm/min≥118Aux. winchFull loadm/min≥70No loadm/min≥118Noise limitCrane exterior noisedB (A)≤118At seated positiondB (A)≤90
