Second-Hand Good Condition Qy50ka 50ton Used Truck Crane
Cruking Engineering Equipment (Xiamen) Co., Ltd.- After-sales Service：Spare Parts
- Warranty：1 Year
- Certification：GS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：58.1m
- Maximum Lifting Weight：50ton
Base Info
- Model NO.：QY50KA
- Shaft Number：3
- Crane Jib：Five-Arm
- Type：Telescopic Boom
- Overall Dimensions：14030*2800*3630mm
- Front Axle Load：16200kg
- Rated Power：276,2000kw,Rpm
- Rated Torque：1560,1200-1500rpm
- Engine：Sc10e380q5,D10.38-50
- Max.Traveling Speed：80km,H
- Wheelbase：1470+4300+1350mm
- Max.Gradeability：45%
- Hydraulic Oil Tank：320L
- Base Boom Length：11.4m
- Full-Extend Boom+Jib Length：43.5m
- Max. Outrigger Reaction Force：490kn
- Transport Package：Nude Package
- Specification：42200kg
- Trademark：CRUKING
- Origin：China
- HS Code：8705109100
- Production Capacity：500sets,Year
Description
QY50K truck crane is a product with high reliability inheriting classical and advanced technology for designing and manufacturing truck cranes of many years and based on mature technology. Special truck crane chassis designed and manufactured by our company, all covered working surface and classic K-series appearance outline is equipped. The operations of cranes are very simple, convenient and flexible. It is widely used for lifting operation and installation work in urban renewal, transportation, ports, bridges, oilfield, industrial and mining enterprises, etc.
