China Dongfeng 5 Ton Knuckle Boom Truck Mounted Crane
Jinan Sinoheng Import and Export Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Maximum Lifting Height：<10m
- Maximum Lifting Weight：5-7t
- Type：Straight Arm
- Max Lifting Moment：10.5 T.M
Base Info
- Model NO.：SQ5ZK3Q
- Max Lifting Capacity：5000kg
- Oil Tank Capacity：90L
- Crane Weight：2011kg
- Power Source：Hydraulic
- Moving Type：Wheel
- Installation：Assembled
- Transport Package：Nude
- Specification：CE, SGS
- Trademark：Dongfeng
- Origin：China
- HS Code：8705102200
- Production Capacity：500 Units Per Month
Description
Model
SQ5ZK2Q
SQ5ZK3Q
Unit
Max Lifting Moment
10.5
10.5
t.m
Max Lifting Capacity
5000
5000
kg
Recommend Power Needed At Recommend Oil Flow
18
18
kw
Max Oil Flow of Hydraulic System
25
25
L/min
Rated Pressure Of Hydraulic System
28
28
MPa
Oil Tank Capacity
90
90
L
Rotation Angle
(360°)All Rotation
(360°)All Rotation
.
Crane Weight
2011
2117
kg
Installation Space
1050
1050
mm
Choice of Chassis
HOWO Chassis ; CA1140PK 2L 3EA80 ; DFL1140B ; EQ1126KJ1 ; HFC1132KR1K3 ; LZ1120LAPT ; EQ1141NBJ2 ; EQ5121GFJ ; EQ5201GFJ6 ; HN1310P29D 6M3 J ; NXG1160D3ZAL1X ;
SQ5ZK2Q Lifting capability diagram
Working radius (m)
2.1
4.44
6.2
8.01
Lifting capacity (kg)
5000
2400
1600
1050
SQ5ZK3Q Lifting capability diagram
Working radius (m)
2.1
4.54
6.3
8.11
9.92
Lifting capacity (kg)
5000
2400
1600
1050
700
Packaging & Shippingshipped by RORO or Bulk ship
