China New 35tons Crawler Crane Quy35 for Sale
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Online Service
- Max. Lifting Height：One Warranty
- Rated Loading Capacity：35ton
- Certification：CE
- Condition：New
- Warranty：1 Year
Base Info
- Model NO.：QUY35
- Rated Loading Capacitys：35ton
- Engine Power：206kw
- Maximum Lifting Capacity *Radius：52m
- Transport Package：Bulk Cargo ,RO-RO
- Specification：50ton
- Trademark：china top
- Origin：China
- HS Code：8426200000
- Production Capacity：100pieces,Month
Description
QUY35A General specifications
Max. rated lifting-load
t
35
Boom length
m
10-40
(Boom + jib) max. length
m
34+12.2
Boom luffing angle
degree
30-80
Hoisting rope speed
m/min.
31-62
Lowering rope speed
m/min.
31-62
Luffing up speed
m/min.
63
Luffing down speed
m/min.
63
Slewing speed
rpm
3.7*
Walking speed
km/h
1.4
Gradeability
%
40
Load moment
t·m
125
Brand & Model of Diesel engine
Shanghai DieselD6114ZG2B
Rated output of diesel engine
kW/rpm
128/2000
Mass of counterweight
t
12.1
Mass of crane (with basic boom)
t
36
Average ground pressure
MPa
0.053
Main hoisting sheave multiple
7
Shipment dimensions of main body(LxWxH)
m
6.35x3.96x3.02
