• Model NO.：XGC85
• L*W*H：13.05*3.4*3.3m
• Gradeability：30%
• Maximum Lifting Moment：341t. M
• Maximum Travel Speed：0.9km,H
• Transport Package：Provided
• Specification：,
• Trademark：SINOMADA
• Origin：China
• HS Code：8429521200
• Production Capacity：100units,Month

Overview Product Description

Crawler crane XGC85 is designed and developed independently in absorption of foreign advanced technology and combined with China domestic work conditions.

Product Parameters



Operating performance parametersMaximum rated lifting capacity of main boom(t)85Maximum rated lifting capacity of fixed jib(t)12Maximum rated lifting capacity of luffing jib(t)-Maximum lifting moment(tm)341Maximum lifting capacity of tower jib(t)-Maximum rated lifting capacity of single pulley at arm end(t)8Maximum rated lifting capacity of special jib(t)-Size parametersMain boom length(m)13~58Main boom luffing angle(°)-3~80Fixed jib length(m)7~19Tower jib length(m)-Maximum size of a single piece in transportation state (L×W×H)(m)13.05×3.4×3.3Fixed jib installation angle(°)10°, 30°Dedicated jib length(m)-Speed parameterMaximum single rope speed of hoisting mechanism(m/min)120Maximum single rope speed of main boom luffing mechanism(m/min)70Maximum single rope speed of jib luffing mechanism(m/min)-Maximum turning speed(r/min)2Maximum travel speed(km/h)0.9Gradeability(%)30Average ground pressure(MPa)0.087Maximum single rope speed of tower arm luffing mechanism(m/min)-Maximum single rope speed of super lift luffing(m/min)-Company Information
