| Item | Value | Remarks | |
| Working performance | rated lifting capacitykg | 25000 | | |
| load moment of basic boom | 980 | | |
| kN.m | |
| load moment of boom lengthkN.m | 573 | | |
| lifting height of basic boom m | 11.5 | | |
| lifting height of boom m | 33.8 | Deformation of the boom is not taken into consideration. | |
| lifting height of jib m | 41.6 | |
| Working speed | hoist rope speed (main winch) m/min | 120 | At 4th layer | |
| hoist rope speed(auxiliary winch) m/min | 100 | At 2nd layer | |
| Boom derricking times | 40 | | |
| Boom extending times | 60 | | |
| Slewing speed r/min | 0~2.2 | | |
| Traveling specifications | traveling speed km/h | 78 | | |
| gradeability % | 37 | | |
| Min. turning diameter m | ≤22 | | |
| Min. ground clearance mm | 220 | | |
| Limits for exhaust pollutants and smoke | Meet with related standards | GB3847-2005 | |
| GB17691-2005 | |
| (National stage III) | |
| Oil consumption per hundred kilometers L | 45 | | |
| Weights | Deadweight in traveling condition | 30000 | | |
| kg | |
| Complete vehicle kerb mass kg | 29870 | | |
| Front axle load kg | 6800 | | |
| Rear axle loadkg | 23200 | | |
| Dimensions | Overall dimensions (L×W×H) mm | 12800×2500×3430 | | |
| Longitudinal distance between outriggersm | 5.36 | | |
| Transversal distance between outriggers m | 6.1 | | |
| Boom length m | 10.5~33.3 | | |
| Boom angle° | -2~80 | | |
| Jib length m | 8 | | |
| Offset ° | 0, 30 | | |
| | | | | |
| Chassis | Model | ZLJ5325 | Code: ZLJ5325V3 |
| Class | II | |
| Engine | Model | WP10.270 | |
