• Model NO.：XCT90
• Maximum Lifting Weight：90000kgs
• Shaft Number：4
• Crane Jib：Six-Arm
• Type：Telescopic
• Max Lifting Capacity：90ton
• Rated Power：297kw
• Total Weight：48000kg
• Length：13985mm
• Width：2780mm
• Height：3990mm
• Speed：90km,H
• Cabin：Full Cabin
• A/C：Yes
• Emission：Euro III
• Warranty：1 Year
• Aftersales Service：Oversea Service, Free Spare Parts, etc
• Control System：Pilot Control
• Certificate：ISO CCC
• Transport Package：Roro Ship , Bulk Ship
• Specification：Mobile crane
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000units,Year

CategoryItemUnitParameter



DimensionOverall lengthmm13985Overall widthmm2780Overall heightmm3990Wheel basemm2000+4000+1500Trackmm2354×2354/2291×2291Front overhangmm2525Rear overhangmm2310


WeightTotal mass in travel configurationkg48000

Axle loadAxle 1kg12000Axle 2kg12000Axle 3kg12000Axle 4kg12000

PowerChassis engine model MC11.40-50WP12.375E50Engine rated powerkW/(r/min)297/1900276/1900
Engine rated torque
N.m/(r/min)
1900/1000~1400
1800/1000~1400







TravelTravel speedMax. travel speedkm/h90Min. travel speedkm/h1.7~3
Turning diameterMin. turning diameterm20Min. turning diameter at boom tip
m
25.2Min. ground clearancemm367Approach angle°21Departure angle°15Braking distance (at 30 km/h )m≤10Max. grade ability%45Fuel consumption per 100 kmL45
