• Model NO.：Rough Terrain Crane
• Type：Telescopic
• Basic Boom：9.7 M
• Max Travel Speed：50 Km,H
• Min Travel Speed：2 Km,H
• Longest Main Boom：31 M
• Transport Package：Roro Ship
• Specification：CE
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000PCS,Year

Dimension

Unit



Overall length

mm

13135

Overall width

mm

3180

Overall height

mm

3750

Weight





Total weight in travel

kg

49000

Power





Engine model



QSB6.7

Engine rated power

kW/(r/min)

194

Engine rated torque

N.m/(r/min)

842

Travel





Max. travel speed

km/h

25

Min. turning diameter

m

12.2

Min. ground clearance

mm

467

Approach angle

°

20

Departure angle

°

17.5

Max. grade ability

%

65

Fuel consumption for 100km

L

-

Main performance





Max. rated total lifting capacity

t

70

Min. rated working radius

m

2.5

Turning radius at turntable tail

m

4.1

Max. lifting torque

kN.m

2033

Full-extend boom

m

11.3

Full-extend boom+jib

m

43.9

Boom length

m

58.1

Working speed





Boom lifting time

s

120

Boom full extension time

s

130

Max. swing speed

r/min

-

Max. speed of main winch (single rope)

m/min

-

Max. speed of aux. winch (single rope)

m/min

2

Product Highlights:

Strong Power of Hoisting, Wide Range of Work
It has 31m main booms, 13m auxiliary booms, with the longest main booms and the highest comprehensive
hoisting performance in the product of the same tonner.

Maneuvering and Flexible, Quick and Efficient
The max speed reaches 50km/h and the max grade ability is 55% and the min. turning radius is 5m. All these
three factors make it flexible. Self-localization and self-locked Jib stowed under booms make it needs no
auxiliary operator and no equipment, and can quickly retract, and efficiently work.

Safe and Reliable, No Worry to Handle
The product is equipped with lifting protection control system in case of overload, over-retracting, and
over-stretching as well as exclusive technology in this field like rear axle-wheel automatic return-control system
and safety-driving automatic protection system. All these elevate its safety performance largely;The product is
equipped with top features in this field, professional matching upgrading and systematic evaluation test.
And it has passed the test like driving 11,000km and 10,000 times hanging. Both ensure its reliability.

Economic and Environmental Protection, with Cost Saving
The product is equipped with an optical matching power transmission system and torque converter with
lockout function, which decreases the oil consumption over 20% at high speed.The one-way stabilized current
control of the parallel hydraulic pressure system reduces the loss of flow; the gravity drop luffing system needs
no extra power and save the oil consumption.

Comfortable to Handle, Convenient to Operate
The product is equipped with full hydro-steering control system and automatic-manual gearbox, which makes
it easy to handle. And the compounded suspension of leaf spring and hydraulic oil tank, and the self-recognition
phased control of rotary cushion technology make the operation stability and comfortable;
