• Maximum Lifting Height：<10m
• Maximum Lifting Weight：11-13t
• Shaft Number：3
• Crane Jib：Three-Arm
• Type：Straight Arm
• Transport Package：Nude
• Specification：Sinotruk
• Trademark：Sinotruk howo
• Origin：China
• Package size per unit product：7500.00cm * 2550.00cm * 3400.00cm
• Gross weight per unit product：10000.000kg

Ton8Type ZZ1107G3815D1Company inner type&/M1W-4110Y21D2755L















Parameters



Overall dimension (LxWxHmm)6995*2330*2650(LxWxH mm)4850*2150*550Drive mode4*2Drive mode4*2Wheelbase (mm)3800Wheel tread (FrontRear mm)1845/1795Min.Ground clearance(mm)210mmFront overhang/Rear overhang(mm)1240/1955Approach angle(°)/Departure angle(°)27/22Max. Speed(km/h)95Max grade ability(%)30Fuel consumption(L/100KM)18.3Min.turning radius(m)7.75mKurb weight(kg)4725Rated load(kg)8000Capacity of cab3Gross weight(kg)12920CabWidth*length2080*1936





Engine

ModelN4E140-42TypeDiesel,foul-cylinder, inline,injection,pressurize,intercoolersDisplacement(L)4260Power/rated speed(km/rpm)105/2800Maximun torque/rotate speed(N.m/rpm)430/1300~1700Gear boxTypeWLY,5forward& 1 reverseSpeed ratio5.51/3.417/2.115/1.381/1.00/0.795/5.128FrameHeight (mm)215Front axle VGD27QBReal axle HGC55QBSuspension 9/12+9B

Braking system



Drive brakeAir brakeParking brakeCutting-off air brakeAuxiliary brakeExhaust brakeCluctch350Electrical applianceNominal voltage24VBettery90AHA/COptionTire8.25R16Fuel tank(L)120LBasic configuration

Radio, sun shield,clutch booster, power steering, adjustable steering wheel,heater,electric control flameout,electrical heating,air dryer,left hand,metallic paint of cab(except white)





ModelSQ3.2SK1QUnitMax Lifting Capacity3200kgMax Lifting Moment6.72T.MRecommend Power14kwMax Oil Flow of Hydraulic System25L/minMax Pressure of Hydraulic System20MPaOil Tank Capacity30LRotation AngleAll Rotation Crane Weight1105/1229kgInstallation Space850mmChoice of ChassisEQ1092FJ;EQ1092FJ1;EQ1092F3GJ1;EQ1081GJ12D5;
DFL1120B;HFC1083K103R1D;EQ5121GFJ;SQ3.2SK1Q Lifting capability diagramWorking radius (m)2.103.005.35Lifting capacity (kg)32001850950



Applications:



The HOWO Light Truck is suitable for transporting all kinds of small goods, such as vegetables, fruits

and so on, also can be used in construction business such as to shipment sand or small stones.



Competitive Advantage:



1) HOWO light truck engine technology is more mature, strong power and low noise. The

vehicle matching science, low fuel consumption, can be fuel-efficient 10-20%.has high

attendance, high efficiency, low cost of the three major characteristics.
2) Strengthen the full adoption of the European heavy truck chassis riveting technology,

forming a frame beam, the bearing capacity of the carriage can be greatly enhanced.

According to the actual load of the version selection.
3) Manchester technology bridge is one of the highlights of HOWO light truck, which is the

application of Chinese cooperation unit bearing heavy duty truck and the German MAN,

achieved 1 million 500 thousand km free maintenance, free adjustment.
4) The international design, cab heroic atmosphere, can be turned 45 degrees. The sleeper

wide seat, convenient adjustment, no blind spot mirrors, in contrast to high grade

interior, a broader vision.
5) Integrated control flat, with engine tachometer, adjustable soft wheel gear. Aluminum

Alloy gearbox shell, 6/8 gear synchronous belt, operate more freely. Fully adapted to

the efficient logistics of HOWO light truck, caused the high attention of the

participants.
6) with all kinds of truck model, which can fulfill your requirement
7) professional import and export dealing procedure, make customs clearance more high

efficiency

8) fast delivery time, we can arrange production according to your needs exactly and

quickly

9) quick and efficient spare parts supply bring you more convenient
10) competitive price, cost-effective
11) based on strong technical support and top level technology make the trucks with high

quality and more reliable

12) the key parts adopt the world's top technology products
