Small Crawler Crane- Quality 100 Ton Crawler Crane Xgc100
Sinomada Heavy Industry (Changsha) Co., Ltd.- Max. Lifting Height：75m
- Rated Loading Capacity：100t
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
- Gradeability：30%
Base Info
- Model NO.：XGC100,QUY100
- Traveling Speed：0-1.57 Km,H
- Engine Power：206kw
- Max. Slewing Speed：1.4r,Min
- Transport Package：Comply with Export Packaging Requirements for Min
- Specification：10.5*3.0*3.35m
- Trademark：Sinomada
- Origin：China
- HS Code：84262000
- Production Capacity：100 Units Per Month
Description
Item
Unit
Specification
Max. rated lifting capacity
Basic-form main boom
t
100
Stationary auxiliary boom
t
15.6
Max. Lifting Torque
t.m
575
Length of Main Boom
m
19~73
Luffing Angle of Main Boom
Working Condition of Main Boom
°
30~ 81
Working Condition of Stationary Auxiliary Boom
30~ 81
Length of Stationary Auxiliary Boom
m
13~25
Max. Single Rope Speed of Hoisting Mechanism (Non-load, Fourth Layer)
m/min
110
Max. Single Rope Speed of Main Boom Luffing Mechanism (First Layer)
m/min
34
Max. Slewing Speed
r/min
1.4
Max. Traveling Speed
km/h
1.3
Gradeability
%
30
Average Ground Pressure
MPa
0.087
Engine Power
kW
206
Overall Weight (Main Hook, Full Counterweight, 19m Boom)
t
104.5
Max. Mass of Single Piece in Transport State
t
32.5
Max. Size of Single Piece in Transport State (L × W × H)
m
10.5×3.0×3.35
