5-32 Ton L Shape Type Single Beam Gantry Crane with Winch Trolley

HENAN NYBON MACHINERY CO., LTD.
  • Certification：CE, ISO9001
  • Condition：New
  • Maximum Lifting Weight：<20t
  • Maximum Lifting Height：25-30m
  • Operation Form：Air Operation+Ground Operation
  • Type：Common Gantry Crane

Base Info

  • Model NO.：L
  • Main Girder Form：Single Girder
  • Product Name：5-32 Ton L Shape Type Single Beam Gantry Crane
  • Control Method：Cabin or Wireless Remote Control
  • Voltage：Customized
  • Capacity：5-32 Ton
  • Span：18-35m
  • Lifting Height：10-12m
  • Rail：P43
  • Transport Package：Special Waterproof Plastic Close for Expor, 40ot
  • Specification：32 Ton
  • Trademark：NYBON
  • Origin：Henan, China
  • HS Code：8426193000
  • Production Capacity：200 Sets,Year

Description

Rated load/ton5 10 16 20Span/m10-40     Lifting height/m30     Working classA3/1bM     Lifting speed/m/min873.5 3.5Trolley running speed/m/min20 202020Crane running speed/m/min 20 202020Dead weight/t10.5~37.5 16.8~5218.9~65  24.5~77 Number of wheel 4444Max. wheel pressure/KN 52.5~12.1 95~183 131~242 167~298Steel track recommended P24 P38 P43 P43Power supply3AC  220~480V  50/60Hz

5-32 Ton L Shape Type Single Beam Gantry Crane with Winch Trolley
5-32 Ton L Shape Type Single Beam Gantry Crane with Winch Trolley
5-32 Ton L Shape Type Single Beam Gantry Crane with Winch Trolley


5-32 Ton L Shape Type Single Beam Gantry Crane with Winch Trolley


1. Q: What's your MOQ?

  A: 1 Set;

2. Q: What's your package?

  A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;

3. Q: What's your delivery period?

  A: Within 10/25/40 days after your prepayment received; exact period should be based on detailed requirements and actual period;

4. Q: What's your warranty period?

  A: 12 months from winches accepted;

5. Q: Do you have engineer oversea installation service?

   A: Yes; We have;

6. Q: What kinds of products do you have?

    A: All kinds of industrial electric winch (especially non-standard); Overhead Crane; Gantry Crane, Electric Hoist; Screw Hoist; Radial/Flat

Gate Hoist; Steel Gate; etc.

7. Q: Could we buy spare parts in local once they are out of work?

    A: Our main electrical parts brand is Siemens or Schneider brand; it's very easy to buy all the world. But if there is any difficulty, we can

post to you by express, such as DHL, UPS, FEDEX, Aramex, etc.

8. Q: Do you provide lift tools?

    A: Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet , pulley blocks, hook, lock catch, wire rope,

fiber rope, etc.

9. Q: Could your winches drag inclined?

    A: Yea, our electric winches could drag horizontal, drag inclined, hoisting vertical.
