• Model NO.：STC750
• Shaft Number：4
• Crane Jib：Five-Arm
• Type：Straight Arm
• Color：Red
• Application：Construction Usage
• Tower Crane Type：Under Slewing Cranes
• Sling Type：Wire Rope
• Main Girder Form：Single Girder
• Power Source：Hydraulic
• Moving Type：Wheel
• Span：6.1 M
• Engine：Weichai
• Transport Package：Nude, Suitable for Shiping
• Specification：ISO
• Trademark：SANI
• Origin：Hunan, China
• HS Code：84269100
• Production Capacity：100 Sets,Month

ItemParametersUnitOverall Length14100mmOverall Width2750mmOverall Height3850mmAlex Base1520+4400+1350mmTotal vehicle mass in travel configuration46000kg1st/2nd Axle Load 20000kg 3rd/4th Axle Load26000 Engine Model--- Engine rated power275/2100kw/(r/min)Engine rated torque1550/1200N.m/(r/min)Max. travel speed80km/hMin. turning diameter12mMin. ground clearance230mmMax. grade ability37%Approach angle20°Departure angle12°Braking distance (at 30 km/h, full load )--mOil consumption per 100km≤55L
